Home > Electrical & Electronics > Relay & Contactor > Contactor > CNGZ 36V-380V New Cj20 ac Contactor

CNGZ 36V-380V New Cj20 ac Contactor

Name: CNGZ 36V-380V New Cj20 ac Contactor
Brand: Aissmy
SKU: 119755407
Availability: InStock

CNGZ 36V-380V New Cj20 ac Contactor thumbnail-1

CNGZ 36V-380V New Cj20 ac Contactor thumbnail-2

CNGZ 36V-380V New Cj20 ac Contactor photo-1

CNGZ 36V-380V New Cj20 ac Contactor photo-2

US$ 2.2 - 28.5 MOQ: 5 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Zhejiang, China

Brand Name:

Aissmy

Model Number:

CJX2(LC1)

Contact Supplier Request Quote Chat Now

Shanxi Aisiman Electric Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

NingBo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Zhejiang, China

Brand Name Aissmy

Model Number CJX2(LC1)

Electricity Type AC

Number of Pole 3

Phase 3

Main Circuit Rating Voltage Other, 220/230/380/400/415/500/660

Main Circuit Rating Current Other, 9/12/18/25/32/40/50/65/80/95a

2015 the latest hottest AC motor contactor price is low

Product Description

Specification

CJX2 series AC Contactor is suitable for using in the circuits the rated voltage up to 660V AC 50Hz or 60Hz, rated current up to 95A, for making & breaking, frequently starting & controlling the AC motor.

AC Contactor Combined with the auxiliary contact block, timer delay & machine- interlocking device etc, it becomes the delay contactor, mechanical interlocking contactor, star-delta starter.With the thermal relay, it is combined into the electromagnetic starter.AC Contactor is produced according to IEC 60947-4, GB14048-4.

CJX2 series AC contactor, small size, light weight, long working life, can assemble different accessories, such as stacking auxialiry contact group, air delay contact, mechanical interlocks, to form time delay contactor, mechanical interlock contactor, star-delta starter, also inset thermal relay to form magnetic starter.

Technical Data

Type	Rated insulation voltage(V)	Conventional thermal current(A)	Rated operation current(A)	Control power(kw)					No .of contacts	Installation Method
				220V	380V	415V	440V	660V
LC1-0910	660	20	9	2.2	4	4	4	5.5	3P+1NO	1with two screws 235mm din rail
LC1-0901	660								3P+1NC
LC1-1210	660	20	12	3	5.5	5.5	5.5	7.5	3P+1NO
LC1-1201	660								3P+1NC
LC1-1810	660	32	18	4	7.5	9	9	9	3P+1NO
LC1-1801	660								3P+1NC
LC1-2510	660	40	25	5.5	11	11	11	15	3P+1NO
LC1-2501	660								3P+1NC
LC1-3210	660	50	32	7.5	15	15	15	18.5	3P+1NO
LC1-3201	660								3P+1NC
LC1-4011	660	60	40	11	18.5	22	22	30	3P+NO+NC	1with three screws 275mm 0r 35mm din rail
LC1-5011	660	80	50	15	22	25	30	33
LC1-6511	660	80	65	18.5	30	37	37	37
LC1-8011	660	125	80	22	37	45	45	45
LC1-9511	660	125	95	25	45	45	45	45
