Help CenterVertical Accumulator
Related Products
I. Function:
This accumulator permits continuous operations of strip processing lines, there by reducing costly delays caused by end of a coil. The operation consists of feeding material into the inside of the super coil accumulator, and then transfer it to the outside diameter until the desire amount of strip storage is accumulated. During this time, the material is continulusly feed inti the tube mill. When the coil end is reached, the incoming material stops for coil joining. Stored material, however, is continuously removed form the outside of the accumulator and pulled into the processing line. Since the accumulated strip is constantly turning, there is virtually no additional load imposed on the tube mill. Sheared and welded strip is temporarily accumulated in this unit for continuous operation of the mill.
II.Technical parameters:
Accumulator type |
Cage type accumulator |
Storing type |
Fixed-coil type, outside input and inside output |
Drive type |
AC adjustable-speed motor |
Pinching speed |
150m/min |
Motor of accumulator |
15KW |
Motor of pinch device |
11KW |
Steel strip width |
40-100mm |
Steel strip thickness |
0.5-3.0mm |
