Flexible and Efficient Maneurop Refrigeration Compressor MT22

Flexible and Efficient Maneurop Refrigeration Compressor MT22 thumbnail-1
Flexible and Efficient Maneurop Refrigeration Compressor MT22 thumbnail-2
Flexible and Efficient Maneurop Refrigeration Compressor MT22 thumbnail-3
Flexible and Efficient Maneurop Refrigeration Compressor MT22 thumbnail-4
Flexible and Efficient Maneurop Refrigeration Compressor MT22 thumbnail-5
Flexible and Efficient Maneurop Refrigeration Compressor MT22 thumbnail-6
Flexible and Efficient Maneurop Refrigeration Compressor MT22 photo-1
Flexible and Efficient Maneurop Refrigeration Compressor MT22 photo-2
Flexible and Efficient Maneurop Refrigeration Compressor MT22 photo-3
Flexible and Efficient Maneurop Refrigeration Compressor MT22 photo-4
Flexible and Efficient Maneurop Refrigeration Compressor MT22 photo-5
Flexible and Efficient Maneurop Refrigeration Compressor MT22 photo-6
US$ 120 - 200 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
Maneurop
Model Number:
MT22
Contact Supplier Request Quote Chat Now
Guangzhou Qilin Environmental Technology Firm
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou/Shenzhen/Hongkong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name Maneurop
Model Number MT22
Type Refrigeration Compressor
Application Refrigeration Parts
Certification CE
Product Description

  Maneurop reciprocating compressor  MT22

  • MT and MTZ series compressors are of the hermetic reciprocating type and are designed for medium and high evaporating temperature applications.Flexible and efficient Maneurop refrigeration compressor MT22
  • The positive benefits of internal motor protection, high efficiency circular valve design and high torque motors provide for a quality installation.
  • MT and MTZ compressors have a large internal free volume that protects against the risk of liquid hammering when liquid refrigerant enters the compressor.
  • MT and MTZ compressors are fully suction-gas cooled. This means that no additional compressor cooling is required and allows the compressors to be insulated with acoustic jackets, to obtain lower sound levels, without the risk of compressor overheating.
Key Feature

   Maneurop compressor MT22  Features



Green, efficient and reliable

  1. The continuous compression inherent in scroll technology makes it the most widely used compression technology in air conditioning and heat pump applications by providing naturally high efficiency and limiting vibration and noise levels. For several decades, Danfoss scrolls have offered all the benefits of scroll technology making Danfoss a leading partner for its customers.
  2. The smart design provides reliable, compact solutions with low sound levels. The ranges are designed to operate with the greenest refrigerants.
  3. Quick electrical connector plugs and equipment simplify the mounting and servicing.
  4. Take advantage of everything Danfoss offers you to drive differentiation!

Flexible and efficient

  1. The performance of air conditioning units depends on their ability to adapt to variations in the climate over the year and to temperature differences during the day.
  2. Consequently the higher efficiency of Danfoss scroll compressors can make a vital difference.
  3. The adaptability of the MT-Series also makes it easier for you to reduce the number of items held in stock.

Environmental compliance

  1. Danfoss leads the industry and sets standards by going beyond current legal regulations and removing environmentally harmful substances from its products. Danfoss is striving to be 100% RoHS compliant and offers acoustic performance that is among the best in the market to respect the environment in residential areas.
  2. Danfoss helps you provide your customers with sustainable solutions without compromising on reliability, endurance and performance.
Technical Data





Models available





Model

Cooling Capacity

Input

Current

COP

Displacement

Oil charge

Weight

Height

Voltage


(W)

(KW)

(A)

(W/W)

(m3/h)

(dm³)

(kg)

(mm)



MT22-4VM

5363

1.89

4.56

2.89

6.63

0.95

23

356

380V,50Hz

MT28-5VM

7378

2.55

4.56

2.89

8.36

0.95

24.5

356

380V,50Hz

MT32-4VM

8064

2.98

4.97

2.7

9.37

0.95

25

356

380V,50Hz

MT36-4VM

9272

3.37

5.77

2.75

10.52

0.95

25.5

356

380V,50Hz

MT40-4VM

10475

3.85

6.47

2.72

11.81

0.95

26

356

380V,50Hz

MT44-4VM

11037

3.89

7.37

2.84

13.26

1.8

36

415

380V,50Hz

MT50-4VM

12324

4.32

8.46

2.85

14.9

1.8

37

415

380V,50Hz

MT56-4VM

13771

5.04

10.27

2.73

16.73

1.8

37

415

380V,50Hz

MT64-4VM

15820

5.66

9.54

2.79

18.74

1.8

37.5

415

380V,50Hz

MT72-4VM

17124

6.31

10.54

2.71

21.04

1.8

39

415

380V,50Hz

MT80-4VM

19534

7.13

11.58

2.74

23.63

1.8

42

415

380V,50Hz

MT100-4VM

23403

7.98

14.59

2.93

29.8

3.9

66.5

540

380V,50Hz

MT125

30429

10.66

17.37

2.85

37.49

3.9

68

540

380V,50Hz

MT144

34340

11.95

22.75

2.87

42.09

3.9

69

540

380V,50Hz

MT160

38273

13.39

22.16

2.86

47.06

3.9

69

540

380V,50Hz



nomenclature



FAQ



1. How long have you been in this field? Where is your company?

We have been in this field for years and we are located in Guangzhou, the capital city of Guangdong Province, near to Shenzhen, Hong Kong, very convenient for shipping.



2. Can you offer us at the best price?

Of course, we always take good care of our clients if both are sincere to establish good relationship.



3. How about the MOQ?

1 unit is ok



4. Shipping methods and lead time?

By Express: 3-5 working days to your door (DHL, UPS, TNT, FedEx...)

By Air: 5-8 working days to your airport

By Sea: Pls advise your port of destination, the exact days will be confirmed by our forwarders,

And the following lead time is for your reference.

Europe and America (25 - 35 days), Asia (3-7 days), Australia (16-23 days)



5. What is the term of Payment?

T/T, L/C, Western Union;

30% T/T in advance, 70% before delivery.



6. Packaging & Shipping:

Packing: PALLET, wooden case or with outer carton, or as per customers' specific requirements.



7. Cooperate Partners:

Copeland, Maneurop, Performer, Blitzer, Danfoss, Sanyo, Daikin, Toshiba GMCC, Hitachi Highly, Embraco,

Mitshubishi, SECOP, etc.



8. What are your main products?

Hermetic Compressor

Refrigeration gas

HVAC maintenance supplies

Flexible and efficient Maneurop refrigeration compressor MT22Flexible and efficient Maneurop refrigeration compressor MT22Flexible and efficient Maneurop refrigeration compressor MT22
