12mm pixel RGB LED Chain
1. This 12mm pixel RGB LED Chain for christmas festive string of addressable RGB LEDs can add color to indoor or outdoor displays.
Much like our addressable RGB digital LED strips, this 12mm RGB led pixel chain of lights is composed of 50 individually sealed 8mm diffused RGB LED and an internal 8-bit PWM LED driver ( 24-bit color for 16 million different shades) like ws2801 / DMX512 / LPD6803/ WS2811, etc.
2. It has a microprocessor that control the RGB LED and provides various dynamic effects of different colors or luminance, that means they are digitally-controllable, you can set to any colors or animates. ( You need to buy a pixel led controller to run it).
3. These 12mm pixel RGB LED Chain for christmas led have a flat square back, the RGB LED and IC driver chip is molded into a 'dot' of silicone, sealed, so they are weatherproof and rugged. With four flanges so they can be pushed into 12mm drill holes in thin sheet material up to 1.5mm/0.06" thick
4. The 12mm pixel RGB LED Chain for christmas are connected by a 4-pin cable. +5V , GND , DAT and CLK .
In both ends there are two JST SM 4-pin connectors that you can connect multiple 12mm led pixel chains in a row. as many as you wish, just watch for how much current they want. We recommend every 50 pcs/ strand should be powerd by power supplies.
Item | 12mm pixel RGB LED Chain |
Model NO. | SY-1515ICRGB |
IC driver | WS2801 / DMX512 / WS2811/ SM16716/ P9813, etc |
Power | 0.3W |
Work Voltage | DC 5V |
Beam Angle | ≥120 |
LED Quantity | 1 pcs DIP 8mm LED |
Emitting color | RGB pixel digital |
Dimension | 26*18*23mm |
Waterproof | IP66 / IP68 |
Life-span | 50,000H |
Certificate | CE&RoHS&EMC |
Warranty | 2 years |
Brightness | Red = 3.3 Lumens/300 mcd, Green = 10 Lumens/1000 mcd, Blue = 2.7 Lumens/300 mcd |
12mm pixel RGB LED Chain detailed images
