Upper Guide Rail Aluminium Profile for Sliding Door

Name: Upper Guide Rail Aluminium Profile for Sliding Door
Brand: XINYIN ALUMINUM
SKU: 119669147

US$ 2.5 - 3.5 MOQ: 300 Kilograms

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Grade:

6000 Series

Temper:

T3-T8

Contact Supplier Request Quote Chat Now

Foshan City Nanhai Xinyin Aluminum Profile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Nansha Huangpu

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Grade 6000 Series

Temper T3-T8

Application Other, Door & Window, wardrobe, sliding door, closet

Shape Other

Alloy Or Not Is Alloy

Model Number XY-TG18-001

Brand Name XINYIN ALUMINUM

Upper guide rail aluminium profile for sliding door

Factory Information:

Factory Establishment:	Established in 2008 year
Sister Factory:	XINHE ALUMINUM
Annual Production Capacity:	Over 100,000 tons
Product Quality Grade:	high-precision level of GB5237 standard
Certification:	ISO9001:2008

Product Information:

Colors:	silver, champagne, gold, bronze, white, black, olive, green, blue, red, grey, iron grey, etc.
Surface treatment:	mill finish, sandblasting, anodizing, powder coating (spraying), electrophoresis, anodized polishing, mechanical polishing, brushing, plastic insulation, spraying wood grain, electrophoresis wood grain, PVDF coating, etc.
Length:	Any length as per customer's request, anodized maximum length is 6.7m
Thickness:	0.9mm (+/-0.1mm) or customized
Maximum Extrusion Size:	300mm x 185mm
Price:	2500USD-3500USD/TON
Packaging:	protective film, pearl cotton / fleece, shrink film, poly bag, kraft paper, or as per customer's request
Payment Term:	By T/T, 30% deposit payment before production, 70% balance payment before delivery
Delivery Time:	20 to 30 days after receiving 30% deposit payment

Production Equipment:

Machine Name	Quantity	Country of Origin
environmentally friendly renewable fuel reflection casting furnaces and hot top type horizontal casting production equipment with high thermal efficiency	8	England
extrusion production lines	46	Taiwan and Japan
powder coating production lines	3	Switzerland
anodized color electrophoretic coating production lines	4	Japan
advanced sandblasting machines	8	China
advanced brushing machines and mechanical polishing machines	a dozen	China
large scale advanced anodized polishing production lines	2	China
crystal-phoresis production line	1	China
fluorocarbon coating production line	1	China
metal heat transfer printing wood grain production lines	10	Italy
thermal insulation plastic inserting machines	2	China
thermal insulation plastic infusion machine	1	China

General Chemical Composition of Alloy:

ALLOY	6061 (%)	6063 (%)	6063A (%)
Si	0.40 - 0.80	0.20 - 0.60	0.30 - 0.60
Fe	0.70	0.35	0.15 - 0.35
Cu	0.15 - 0.40	0.10	0.10
Mn	0.15	0.10	0.15
Mg	0.80 - 1.20	0.45 - 0.90	0.60 - 0.90
Cr	0.04 - 0.35	0.10	0.05
Zn	0.25	0.10	0.15
Ti	0.15	0.10	0.10
Others (each)	0.05	0.05	0.05
Others (total)	0.15	0.15	0.15
Al	Remainder	Remainder	Remainder

Mechanical Properties of Sections under Room Temperature:

(Not less than) (≥) Tensile strength test Hardness test

Alloy	State	Tensile strength Mpa	Non-proportional stretching stress	Stretching rate %	Sample thickness mm	HV	HW
6061	T4	180	110	16	- -	- -	- -
6061	T6	265	245	8	- -	- -	- -
6063	T5	160	110	8	0.8	58	8
6063	T6	205	180	8	- -	-	-
6063A	T5	200	160	5	0.8	65	10
6063A	T5	190	150	5	0.8	65	10
6063A	T6	230	190	5	- -	- -	- -
6063A	T6	220	180	4	- -	- -	- -

Anodic Oxidation of Aluminium Profile Finishing:

Class of thickness	Minimum average film thickness / μm	Minimum local film thickness / μm
AA10	≥ 10	≥ 8
AA15	≥ 15	≥ 12
AA20	≥ 20	≥ 16
AA25	- -	≥ 25

Note: Generally, our anodized aluminium profiles are produced as per grade AA10, or according to client's special request.

Electrophoresis of Aluminium Profile Finishing:

Class of thickness	Anodic oxidation film thickness on measuring part / μm	Lacquer film thickness on measuring part / μm	Combined film thickness on measuring part / μm
A	≥ 9	≥ 12	≥ 21
B	≥ 9	≥ 7	≥ 16

Note: Generally, our electrophoresis aluminium profiles are produced as per grade B, or according to client's special request.

Coat Performance of PVDF sprayed aluminium profiles:

Coating type	Average thickness coating / μm	Minimum local thikcness of coating / µm
2-spraying	≥ 30	≥ 25
3-spraying	≥ 40	≥ 34
4-spraying	≥ 65	≥ 55

Note: Because the complex of the cross section of profile, the thickness coating lower than the regulated value is allowed in some parts such as inner angle and cross drain, but reveal of inside is not allowed.

Gloss	60 degree gloss value complying with the contract, with a tolerance of ±5 gloss unit value	Out look quality	Coating smooth and uniform, no defect (such as flow mark, wrinkle or air bubble) which affect the using is not allowed
Color and chromatic aberration	Substantial agreement with the standard color sample in contract	Hardness	≥ 1 H
Adhesion	Dry, wet and adhesion should be up to grade 0	Impact	After facing impact, no crack or falling off

Thermal Insulation Aluminium Profile:

Vertical shearing characteristic value N/mm; Horizontal pull characteristic value N/mm

Test item	Complex mode	Room temp.	Low temp.	High temp.	Room temp.	Low temp.	High temp.	Thermal insulation deformation average value
Vertical shearing test	Stripe	≥ 24	≥ 24	≥ 24	≥ 24	- -	- -	- -
Horizontal pull test	Injection	≥ 24	≥ 24	≥ 24	≥ 24	≥ 24	≥ 24	- -
High temp. lasting burthen test	Stripe	- -	- -	- -	- -	≥ 24	≥ 24	≤ 0.6
Hot recurrence test	Injection	≥ 24	- -	- -	- -	- -	- -	≤ 0.6

Matually agreement, properties test is not compellent, can be vertified by comparing similar products, but similar products properties result comply with the regulation.

Outlook quality: A bit coating flaw in thermal insulation stripe syntactic part, but flaw in basis material is not allowed.

In 2012 1.obtained the "certificate of Gold Cup Prize for non-ferrous metal product quality"

2."Big tax-payer" of Gaoming District, Foshan City

3.Won the title of "Grade-3 safe-production standardized enterprise"

In 2013 1. won the title of "Famous Chinese Brand"

2."Preferred supplier of 2013 China low carbon environmentally friendly aluminium profile building material procurement"

3."Admittance of 2013 China health environmentally friendly low carbon building material information verification, query and promotion platform"

4."2012 Contract-Abiding and Credible Enterprise of Guangdong Province"

5.The title of "Nantional quality and integrity excellent enterprise"

6.The title of "National stable qualified products in quality inspection"

7.Passed "quality vertification by China Quality and Technical Supervision Association"
