Specifications
Aluminum truss Section/exhibition display booth1.Material:Aluminum 6061/T6/6082
2.Type:Spigot/Bolt,Ladder/Triangle/Square
ALUMINUM SQUARE SPIGOT TRUSS, SCREW TRUSS
- Triangle truss & square truss
- Screw truss & spigot truss
Truss system is used for wedding, party, exhibition, trade
show, concert, advertisement, indoor or out door celebration
and so on .We are ISO9001 tested factory ,passed TUV,SGS
certificate .All Products are available for Customization .You
are welcomed to visit our online company introduction through
/ www.rptruss.en.china.cn
which introduce our company in detailed and cover our latest
products line .
Product Name: Aluminum truss Section/exhibition display booth/12inch aluminum square truss
Specification:
Model: RP-BSQU400 Material:T6061 T6 6082 | ||||
Main Tube:50*3mm Vice Tube:25*2mm Brace Tube:25*2mm | ||||
Length(M) |
1 |
2 |
3 |
4 |
N.W(kg) |
12.50 |
20.30 |
26.50 |
36.50 |
Note: Unit Length could be 0.5M to 4M ,usually 3M is suitable for packing | ||||
Span(M) |
Distribute weight |
Deflection(mm) |
Center point load |
Deflection(mm) |
2M |
2000kg |
1 |
800kg |
1 |
4M |
1780kg |
7 |
730kg |
8 |
6M |
1540kg |
15 |
668kg |
12 |
8M |
1220kg |
23 |
600kg |
22 |
10M |
1050kg |
31 |
510kg |
33 |
| 12M | 830kg | 40 | 433kg | 43 |
| 14M | 665kg | 50 | 365kg | 60 |
| 16M | 500kg | 75 | 300kg | 77 |
Other Sizes available:
250mmx250mm |
300mm*300mm |
400mm*400mm |
450mm*450mm |
500mm*600mm |
520mm*760 mm |
Main Tube (diameter *thickness):50*2mm & 50*3mm |
Brace Tube (diameter*thickness):20*2mm & 25*2mm |
Product Pictures shows
We also produce following square truss:
Spigot Type :
↓
Circular Type
↓
We also provide Truss design projects :
Usages :
Company Introduction
Dongguan Rich Power Performance Equipment Factory is a professional manufacturer of Aluminum Lighting Truss,Moble Stage,Flight Case,Dance Floor,Pipe and Drape,Rubber Stage Cable protector,Aluminum barricade etc,our products are extensively used in performance industries .
Rich Power lacated in Maihui Industry Zone,Huangjiang Town ,Dongguan City,Guangdong Province ,China which covers more than 2500sqms with modernize shops,we prossess complete series production equipments like advanced CNC precision lathe,Milling machine,punching machine,hydraulic lamp fram wellding platform ,digital cutting machine,automatic pressure aluminum-cutting machine and so on
All of our products had passed ISO9001:2008 quality management system certification and Germany TUV safty certificate . We have an excellent work team like professional designers and experienced innovative team and QC department to provide top-quality products for all clients. The quality and technique was fully reconized by our customers from all over the world
