Home > Packaging & Printing > Packing Machinery > Multi-Function Packing Machine > Carbon Powder Auger Weighing Filling Machine
Carbon Powder Auger Weighing Filling Machine
US$ 3,000 - 20,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Function:
Filling, Sealing
Application:
Chemical, Food
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Additives Weighing Filling MachineUS$ 3,000 - 20,000MOQ: 1 Set -
High Speed and Accuracy Auger Filling MachineUS$ 3,000 - 15,000MOQ: 1 Set
-
Instant Drink Powder Auger Filling MachineUS$ 3,000 - 15,000MOQ: 1 Set
-
Pharmaceutical Powder Auger Filling MachineUS$ 3,000 - 15,000MOQ: 1 Set
-
Agriculture Pesticide Auger Filling MachineUS$ 3,000 - 15,000MOQ: 1 Set
Condition
New
Function
Filling, Sealing
Application
Chemical, Food
Packaging Type
Bags
Packaging Material
Plastic
Driven Type
Electric
Voltage
208-415
Power
3.2KW
Place of Origin
Jiangsu, China
Model Number
TC-D2
Dimension(L*W*H)
1130-950-2800mm
Certification
CE,ISO
After-sales Service Provided
Engineers available to service machinery overseas
Descriptive abstract:
This model is designed mainly for the fine powder and small granular which easily to spout dust and high-accuracy packing requirement. Based on the feedback sign given by below weight sensor, this machine do measuring, two-filling , and up-down work ,etc. It is specially suitable for filling additives, carbon powder, dry powder of fire extinguisher, flour, milk powder and other which needs high packing accuracy.
Main features:
- Ø Delta Servo motor control : Drive screw for dosing and filling, perform stably, and with high accuracy. Up-down lifer also control by servo, Few dust spouts out when filling.
- Ø PLC control, touch screen display, easy to operate.
- Ø Load cell detected the filled weight and send signal to do fast filling and slow filling and guarantee the high packaging accuracy.
- Ø With handwheel to adjust the height to suit different size container
- Ø Change screw for different range weight dosing, different filling pulse preset for different density /character material easy get high accuracy
- Ø With absorb pipe for dust vacuum into the outer collector to keep the workshop
Cleaning
- Ø Made of stainless steel, meet GMP standard
- Ø Standard model with level split hopper, easily to be fixed and unload ,easy for inner cleaning
- Ø Level sensor on the top of the hopper to control the feeding machine automatic work
- Ø Process: put container on the machine → container raise → fast filling,container declines → weight reaches the pre-set number → slow filling→ weight reaches the target number → take the container away manually
Main Technical Data:
Model |
BYD-TC-D2 |
Dosing range |
1kg-50kg |
Packing accuracy |
1-20kg, ≤±0.1-0.2%; >20kg,≤±0.05-0.1% |
Filling speed |
2-25 times per min |
Hopper |
100L level split hopper |
Power Supply |
3P AC 208-415V 50/60HZ |
Total Power |
3.2Kw |
Total weight |
500kgs |
Air supply |
6kg/cm2 0.1m3/min |
Overall Dimension |
1130*950*2800mm |
Send Inquiry to This Supplier
Business Type
Manufacturer, Trading Company
Year Established
2011
Factory Size
1,000-3,000 square meters
Total Employees
11 - 50 People
