ASTM B 550 702 Zirconium Bar

Name: ASTM B 550 702 Zirconium Bar
Brand: BJHX
SKU: 119643585
Availability: InStock

ASTM B 550 702 Zirconium Bar thumbnail-1

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

Shaanxi, China

Brand Name:

BJHX

Model Number:

Contact Supplier Request Quote Chat Now

Baoji City Hengxin Rare Metal Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shaanxi, China

Brand Name BJHX

Model Number HX

Application industry, nuclear reaction, nuclear field

Shape round

Material Zirconium

Dimensions diameter(mm):3.0-6.5 length(mm):>500 and so on

Chemical Composition Zirconium

Specifications

1.Zirconium Bar
2.Grade: R60702, R60704, R60705
3.Density: 6.51g/cm3
4.Purity:99.6%min.

Zirconium bar

1.Standard:ASTM B550,R60702,R60704 and R60705

2.Size:Dia(0.5—160mm)*L, as your requirement

Designation	Products name	Surface condition	Diameter(mm)	Length
Zr702	Zirconium wire	Annealing Cold-worked	0.8~<2.5	500~1000
	Zirconium wire	Annealing Cold-worked	2.5~13	500~3048
	Zirconium bar	Annealing Heat process	6.35~<12.7	1000~3048
			12.7~<38.1	1000~3048
			38.1~<150	1000~4064

3.Grade: ASTM B550,R60702,R60704,R60705

4.Density: 6.51g/cm3

5.Purity: >= 99.95%

6.Standard: ASTM B550

7.Different sizes are available

8.Application: Medical, industrial, metallurgical, etc.

9.Chemical composition:

Chenmical composition of Zirconium 702 and 705

	Cr+Fe	Hf	C	N	H	Nb	O	Zr+Hf
Zr702	0.2 max.	4.5 max.	0.05 max.	0.025 max.	0.005 max.	/	0.16 max.	99.2 min.
Zr705	0.2 max.	4.5 max.	0.05 max.	0.025 max.	0.005 max.	2.0-3.0	0.18 max.	99.5 min.

10.Related Zr Products :

zirconium
Grade Zr2 Zr4 Zr60702 Zr60705
Production	Standard	Size
Zirconium bar	GB8769-88 ASTMB550	dia(6-120mm)*(50-2500mm)
Zirconium wire	ASTMB550	dia(0.5-6mm)*L
Zirconium plate	ASTMB551	(thkness1.0-35mm)(W50-500mm)(L10-2000mm)
Zirconium tube	ASTMB523	OD(6-100mm)*(L50-3000mm)
Zirconium foil	ASTMB628	thkness0.05-6mmW20-150mmL

Hengxin Metal is specialized in supplying high purity tantalum niobium zirconium titanium and other refractory metal and their semi-finished products such as plate, sheet, rod, tube, wire, fasteners, crucible, sputtering target, etc. for chemical, high temperature, electronics and other industy.

Pure metal: Niobium (99.9%, 99.95%), Tantalum (99.9%, 99.95%) Zirconium(Zr0, Zr 2 Zr 4)

Alloy: Nb-1%Zr, Nb-10%Zr, Nb-47%Ti, Ta-2.5%W, Ta-10%W

Shape: rod, bar, plate, sheet, foil, tube, wire, crucible, boat, fastener, sputtering target, customer-design shape

Standards: ASTM B392, 393, 394, ASTM B708, 365, 521...
