Home > Products > Zirconium products > pure Zirconium plate in Minerals & Metallurgy
pure Zirconium plate in Minerals & Metallurgy
- 100 Piece / Pieces per Month
- Shanghai Tianjin
- T/T
Product Details
Place of Origin: | Shaanxi, China | Brand Name: | BJHX | Model Number: | pure Zr, Zr2,Zr4 |
Application: | High temperature; Chemical, Medical, Industry, Spaceflight | Shape: | sheet or roll | Material: | Zirconium |
Dimensions: | On request | Chemical Composition: | Zr 702 |
Product Description
Specifications
Zirconium plates and Zirconium alloy platesSpec.: ASTM B551,R60702
Size: 1.0-10mm thickness*W100-1000mm*1000mm
Zirconium plates and Zirconium alloy plates
Spec.: ASTM B551,R60702,R60704 and R60705
Size: 1.0mm to 35mm thickness
Zirconium and Zirconium alloy plates and sheets:
Spec.: ASTM B551,R60702,R60704 and R60705
Size: 1.0mm to 35mm thickness x 50mm to 1000mm width x up to 2500mm long
Zirconium is a grayish silver, dense, ductile, very hard, easily fabricated, and highly corrosion resistant metal. It is part of the refractory metals group and occurs naturally in the mineral tantalite, always together with the chemically niobium.
1. Zirconium ingot, billet, slab
2. Zirconium plate, sheet, foil, strip, ribbon
Standards: ASTM B551, R60700, R60702, R60704, R60705, R60706, Zr2, Zr4, AMS, MIL, JIS, R60001, R60802, R60804, R60901, R60904
Size available: Thick 0.02mm Min * Wide 1200mm Max * Long 3000mm max
3. Zirconium round rod, rectangular bar
Standards: ASTM B351, R60001, R60802, R60804, R60901, R60904, Zr2, Zr4, R60700, R60702, R60704, R60705, R60706
Size available: Outer Diameter 3mm ~ 350mm * Long 6000mm max
4. Zirconium wire
Standards: ASTM B351, R60001, R60802, R60804, R60901, R60904, Zr2, Zr4, R60700, R60702, R60704, R60705, R60706
Size available: Outer Diameter 0.05mm min
5. Zirconium tube, pipe
Standards: ASTM B523, Zr2, Zr4, R60702, R60704, R60705, R60706, JIS, DIN
For seamless, size available:
OD 4-115mm * Wall thick 0.2~8mm * Long 15000mm max
For welded, size available:
OD 80~ 650mm * Wall thick 1 ~ 10mm * Long 15000 max
6. Zirconium forgings and castings
7. Featured Zirconium and zirconium alloys
Zr702 Target
Zr702, Zr705, Zr706
Construction for rectangle target: single piece or multiple pieces with butt or beveled jointed
Competitive pricing, stable quality, quick delivery
Chenmical composition of Zirconium 702 and 705 | ||||||||
Cr+Fe | Hf | C | N | H | Nb | O | Zr+Hf | |
Zr702 | 0.2 max. | 4.5 max. | 0.05 max. | 0.025 max. | 0.005 max. | / | 0.16 max. | 99.2 min. |
Zr705 | 0.2 max. | 4.5 max. | 0.05 max. | 0.025 max. | 0.005 max. | 2.0-3.0 | 0.18 max. | 99.5 min. |
Hengxin Metal supply kinds of metal & alloy sputtering target for various industries in a wide range of shapes and sizes.
Metals & alloys
Chromium
Hafnium
Molybdenum, Mo-Nb, Mo-Ti, Mo-W
Nickel, Ni-Cr, Ni-V
Niobium, Nb-Ti, Nb-Zr
Tantalum, Ta-W
Titanium, Ti-Al, Ti-Cr, Ti-Cu, Ti-Pd
Tungsten, W-Ag, W-Re
Zirconium, Zr-Ti
Purity: 99%-99.999%, dependant on different materials
Shape and form:
Square, rectangle, circular, triangular, rotatable
Single piece or multiple pieces construction. Jointed by butt or beveled for multi-segmented targets.
OEM design available
Surface and tolerance:
Precision fabricated and grounded. Roughness Ra 0.8-Ra 3.2 for target surface
Process:
HIP, Vacuum melting or Press-sintered. Dependant on different materials and application.
Typical application:
Flat Panel Displays, Optical Discs, Automotive & Architectural Glass, WEB Coating, Decorative, Hard Coatings, Solar Cells, Magnetic Data Storage Devices, Semiconductors, Optical Communications, Electron Microscopy
