Multi-Functional Stone Splitting Machine Granite
US$ 5,000 - 7,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
TIANJUN
Model Number:
TJ-S74
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2015 Multi-Functional Stone Splitting Machine, Multi-Functional Stone Splitting MachineNegotiableMOQ: 1 Set -
2015 Stone Machine, for Splitting Stone Into Two in Natural SurfaceUS$ 6,000 - 8,000MOQ: 1 Set
-
TJ-S95 High Pressure Stone Cutting Machine Tools for FloorUS$ 8,000 - 10,000MOQ: 1 Set
-
TJ-S240 Lasered Stone Splitting Machine,crusher for BranchesUS$ 13,000 - 20,000MOQ: 1 Set
-
2016 Stone Machine, Stone Splitting MachineUS$ 1,000 - 3,000MOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
TIANJUN
Model Number
TJ-S74
Condition
New
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
ure:0-40T2.max.trip: 20(cm)
3.Hydraulic Oil Grade: 46#
4.power: 4kw
5.outside size: 100*80*200cm
TJ-S74 Multi-Functional Stone Splitting Machine, stone cutting machine
Technical datas
| Outside size:(cm) | 100*80*200cm | ||||
| Weight | 0.9T | ||||
| Power | 4kw | ||||
| Voltage | 380V | ||||
| Frequency | 50HZ | ||||
| Pressure | 0-40T | ||||
| Maximum Trip | 20cm | ||||
| Knift Length | flat / folio / single-knift | ||||
| oil pump pressure | 20mpa | ||||
| flow rate | 16L | ||||
| Diameter of oil cylinder | 140 | ||||
| oil tank capacity | 70L | ||||
| Applicable Moulds | Splitting Mould Stamping Mould Single-Segmented Mould | ||||
| Hydraulic Oil Grade | 46# |
| Advantage: | |||||
| 1. The oil cylinder can up-down moving autimatically to adust the distance. | |||||
| 2. It has the induction system to prevent hands to worktable. | |||||
| 3. The worktable can open for three sides, it will larger the area of the worktable. |
Machine photos for reference:
After splitting:
After stamping:
