Stone Cutting Machine, Machine for Tile Cutting, Cut Machine
US$ 24,000 - 27,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
Tianjun
Model Number:
TJQH
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
TJ06 DQ450 Automatic Multi-Function Stone Cutting Machine,cutting TileUS$ 11,000 - 18,000MOQ: 1 Set -
Portable Cutting Machine,stone Machine, Quality ProductsUS$ 500 - 1,500MOQ: 1 Set
-
TJ04-1200/1600/1800 Automatic Stone SawUS$ 1,800 - 2,500MOQ: 1 Set
-
Stone Cutting Machine, Granite and Marble Stone CuttingUS$ 6,000 - 8,000MOQ: 1 Set
-
Stone Cutting Saw, Portable Stone SawUS$ 1,000 - 1,800MOQ: 3 Sets
Place of Origin
Fujian, China
Brand Name
Tianjun
Model Number
TJQH
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Stone cutting machine, automatic type.Machine for tile cutting, cut machine.
With infrared system, accuracy.
Faster work.
Stone cutting machine, machine for tile cutting, cut machine
Cutting machine,edge cutting machine,stone equipment,bridge type edge cutting machine,stone machine
Description:
1.Bridge movement by means of precise linear guide ways
2.Z axis movement by lead screw
3.Magnetic rule for slicing measure
| Technical data | |||||||||
| Name | Unit | TJQH-800 | |||||||
| Blade diameter | mm | Φ800 | |||||||
| Worktable dize (Max. cutting size) | mm | 3200×2000 | |||||||
| Blade up/down stroke | mm | 400 | |||||||
| Main motor | kw | 18.5 | |||||||
| Feeding motor | kw | 2.2 | |||||||
| Slicing motor | kw | 1.1 | |||||||
| Motorized blade tilt angle | 0°--- 45° | ||||||||
| Worktable rotation angle(by hydraulic) | 90° or 360° | ||||||||
| Worktable upturning angle | 0°--- 85° | ||||||||
| Voltage/Frequency | V/HZ | 380V/50HZ | |||||||
| Dimensions(L×W×H) | mm | 6300×4700×2800 | |||||||
| Weight | kg | 6800 | |||||||
Stone edge cutting machine photos:
