Stone Block Cutting Machine Blade 1600mm
Negotiable
MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
TIANJUN
Model Number:
LCZQ-160/160A
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Stone Block Cutting Machine LCZQ-160/160ANegotiableMOQ: 1 Unit -
Portal Efficient Multiple Stone MachineNegotiableMOQ: 1 Unit
-
With ISO & CE, Block Machine, Marble Block Cutting MachineUS$ 22,000 - 28,000MOQ: 1 Unit
-
Portal Two-Way Block Stone Cutting MachineNegotiableMOQ: 1 Unit
-
2015 Granite Marble Block Cutting Maching,block Machinery, Granite Bridge SawUS$ 24,000 - 26,500MOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
TIANJUN
Model Number
LCZQ-160/160A
Specifications
1.cutting marble,granite blocks into slab2.can hang 2pcs or 1pc blad when you choose different mode
Single-column supported single-armed overhung type structure is adopted for LCZQ-160/160A Fully Automatic Stone Cutting Machine. Novel in whole-machine design, the machine features a pair of bevel gears with two-stage gear transmission adopted for the headstock ensuring more stable operation. The machine can perform all-process automatic cutting according to preset parameters such as cutting depth, piece thickness, etc. It turns out flat and smooth stone surfaces with low energy consumption and high production efficiency.
| Technical data | |||||||
| Name | Unit | LCZQ-160 | LCZQ-160A | ||||
| Blade diameter | mm | Φ1600-Φ1800 | 2(1-Φ1600,1-Φ940) | ||||
| Max cutting size | mm | 3000×1200×650(750) | 3000×1200×650 | ||||
| Blade vertical stroke | mm | 900 | 900 | ||||
| Power of maindrive | kw | 18.5 | 22 | ||||
| General power | kw | 21.65 | 25.15 | ||||
| Water consumption | m3/h | 5 | 6 | ||||
| Dimensions(L×W×H) | mm | 6000×2900×3300 | 6000×2900×3300 | ||||
| Voltage/Frequency | V/HZ | 380V/50HZ | |||||
| Weight | kg | 4000 | 4000 | ||||
