Home > Manufacturing & Processing Machinery > Stone Processing Machinery > Stone Cutting Machine > Stone Machine, Granite and Marble Cutting Machine
Stone Machine, Granite and Marble Cutting Machine
US$ 16,000 - 22,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Stone Cutting Machine
Use:
Granite
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Multi Blade Cutting Stone MachineUS$ 13,000 - 15,000MOQ: 1 Unit -
TJXD-3000 Numerical Control Wire Saw Machine(separate)NegotiableMOQ: 1 Set
-
LTJZJ Segment Granite Stone Cutting MachineUS$ 6,000 - 7,000MOQ: 1 Set
-
LCZQ-160/160A Automatic Stone Cutting MachineUS$ 9,000 - 11,000MOQ: 1 Set
-
Block Line Wire Saw Machine(separate),block MachineryUS$ 43,000 - 47,000MOQ: 1 Set
Condition
New
Type
Stone Cutting Machine
Use
Granite
Place of Origin
Fujian, China
Brand Name
TIANJUN
Model Number
LCTG-160
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
Stone machine for cutting blockboth for granite and marble
longer life-span
high efficiency
good quality
LCTG-160 (hydraulic up/down) high efficiency multi-blade stone cutting machine
LCTG-160 Large-scale Stone Cutting Machine adopts a forward protrusion frame structure. Its widely used for the processing of granite and marble thin plate. Its stable and highly-efficient.
| Technical data | |||||||||
| Name | Unit | LCTG-120 | LCTG-160 | LCTG-220 | LCTG-250/280 | ||||
| Number of blades | pc | 18-Φ1200 | 9(3-Φ1600,3-1150,3-Φ690) 12(6-Φ1600,6-940) 16(8-Φ1600,8-940) | 1-Φ2200,1-1600,1-Φ940) | 1-Φ2500,1-Φ2800) | ||||
| Blade verical stroke | mm | 1000 | 1000 | 1000 | 1300 | ||||
| Max cutting size | mm | 3500×1300 ×450(475x2) | 3500×1300x650 | 3500×1300x950 | 3500× 1300×1050 3500×1300 ×1250 | ||||
| Main motor power | kw | 55 | 45 / 55 / 75 | 37 | 37/45 | ||||
| Water consumption | m3/h | 16 | 16 | 12 | 12 | ||||
| Dimensions(Lx W xH) | mm | 9000×4200 ×5600 | 8500×4000 ×5500 | 8500×4000 ×5500 | 8500×4000 ×5500 | ||||
| Voltage/Frequency | V/HZ | 380V/50HZ | |||||||
| Weight | kg | ≈8500 | ≈8500 | ≈8500 | ≈8500 | ||||
QUALITY CONTROL:
STONE FAIR:
OUR CUSTOMERS COVER:
OUR COMPANY:
Contact US:
Send Inquiry to This Supplier
Business Type
Trading Company
Year Established
2006
Factory Size
Below 1,000 square meters
Total Employees
11 - 50 People
