Home > Industrial Equipment & Components > Welding Equipment > Plastic Welder > 50kw Belt Welding Machine

50kw Belt Welding Machine

Name: 50kw Belt Welding Machine
Brand: DAVISON
SKU: 119600441
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Place of Origin:

China

Brand Name:

DAVISON

Model Number:

DXHT5-50-E

Contact Supplier Request Quote Chat Now

Ningbo Davison Machinery Manufacture Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

NINGBO

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin China

Brand Name DAVISON

Model Number DXHT5-50-E

Voltage 380V

Power 50KW

Frequency 13.6Mhz

Welding Area 1500mmX300mm

Dimensions 5260 X 1330 X 2200mm

Usage conveyor belt welding

After-sales Service Provided Engineers available to service machinery overseas

Characteristics

1.NL-5557 high frequency sparking protection system,sensitive.It can protect electron tube,mold and material.

2.High power head of machine,pressure can be adjusted freely

3.It adopts high frequency filtering device to make sure of lowest high frequency interference

4.It adopts coaxial oscillator with low loss.The output power is strong to save the welding time and increase the production output.

5.It adopts stepless heating device:the temperature can be adjusted according to different products.

6.It adopts digital display device to make sure it is easy to adjust and fix position accurately.

7.It adopts preheating protection system,prolong life of electron tube,improve the economic benefit.

8.The traditional process of PVC conveyor belt has been greatly improved.Improve the production efficiency,shorten the welding time,ensure the quality of the products

SPECIFICATIONS

MODEL	DXHT5-50-E
OUTPUT POWER	50KW
FREQUENCY	13.6Mhz
VOLTAGE	380V
UPPER ELECTRODE	1500X300mm
LOWER ELECTRODE	1850X380mm
DISTANCE BETWEEN ELECTRODES	100mm
PRESSURE TYPE	OIL AND AIR BLEND
MAX PRESSURE	50000KG
OUTPUT POWER TUNER	ELECTRIC
SIZE	5260X1330X2200m

COMPANY INTRODUCTION:

Ningbo DAVISON Machinery Manufacture Co., Ltd. integrates research, production and sales such as below machines and parts:

1, high frequency plastic welding machines (high frequency machine),

2, ultrasonic plastic welders,

3, cutting machines,

4, packaging machines,

5, skin packaging films, stretch films, protective film, etc.

Various non-standard machinery equipment and imitation of imported equipment are available to the specific requirements of customers. Moreover the design and producing of moulds as well as sampling service can also be offered by us.

Since foundation in 1999, our company has constantly carried forward rigid quality control, guided by customers demand, aimed for customers' satisfaction, persisting on "quality first, customers utmost", and striving to offer optimal products and efficient after-sales service for customers domestic and oversea!
