Help CenterARTONE PD-4200 Series Professional 2000 Watt Amp
Related Products
-
PD-1200 Series Public Address 200W to 1000W Class d 200 Watt AmpUS$ 1 - 1,800MOQ: 1 Piece -
ARTONE PD-4200 Series Professional Class d 2000w Power AmplifierUS$ 1 - 2,500MOQ: 1 Piece
-
PD-2200 Series Class D 600w Audio Mixer AmplifierUS$ 288 - 890MOQ: 5 Pieces
-
ARTONE PD-4200 Series Class d 4 Channel 1u AmplifierUS$ 1 - 2,500MOQ: 1 Piece
-
PD-1200 Series Professional Class d Dsp Audio Power AmplifierUS$ 1 - 1,800MOQ: 1 Piece
Features
- Class D amplifier with switch power;
- Power range from 200W x 2 channel to 2000W x 4 channel for select;
- Good sound performance, work in high efficiency up to 90%;
- Reliable design of independent dual / four channel module;
- 19’’ standard rack install design;
- Compact and small at 1U size only;
- Mono and stereo switch;
- LED indicators for power, signal, clip and overload;
- Low EMI, sufficient protection include shortcircuit, overload, over temperature and high frequency protect.
Description
The Professional Digital 4 Channel Amplifier PD-4200 PD-4400 PD-4600 PD-4800 PD-4010 PD-4012 is designed in high reliability and efficiency, have power rating from 200W x2 to 1200W x 2. They are featured of line input, speaker output, provides speaker output at 4/8 ohm. It work efficient to supply power to stage sound system, reliable for medium or large sound system.
Application and Use Places
ARTONE Professional Digital 2 Channel Class D Amplifier PD-4200 PD-4400 PD-4600 PD-4800 PD-4010 PD-4012 is ideal to use in professional stage show, KTV, DISCO BAR, concert performance, outdoor dance, etc places
The Professional Digital 2 Channel Amplifier module PD-4200 PD-4400 PD-4600 PD-4800 PD-4010 PD-4012 works excellent in professional sound system, reliable for sound amplifier and power distribute, easy and quick to connect a medium or large sound system for your project, enable the song and performance work well.
Specification
Model No. |
PD-4200 |
PD-4400 |
PD-4600 |
PD-4800 |
PD-4010 |
PD-4012 |
|
|
Power |
@ 8Ω |
200W x 4 |
400W x 4 |
600W x 4 |
800W x 4 |
1000W x 4 |
1200W x 4 |
@ 4Ω |
350W x 4 |
700W x 4 |
1000W x 4 |
1400W x 4 |
1600W x 4 |
2000W x 4 |
|
Output Voltage |
40V |
57V |
70V |
82V |
90V |
98V |
|
Input Sensitivity (1KHz) |
Balanced 1V |
||||||
THD (1/8 power, 1KHz) |
0.01% |
||||||
Frequency Response (20-20KHz) |
0.5dB |
||||||
Input Impedance |
Balanced 20KΩ, Unbalanced 10KΩ |
||||||
S/N Ratio |
100 dB |
||||||
Channel Separation |
80 dB |
||||||
Damping Factor |
400 |
||||||
Type / Class |
Class D amplifier |
||||||
Protection |
shortcircuit, overload, over temperature and high frequency |
||||||
Power Supply |
220-250V (45-65Hz) |
||||||
Cooling Method |
Fan sink, variable speed |
||||||
LED Indicator |
Power, Signal, Clip, Protect |
||||||
Audio Input / Output |
XLR Input / Speakon Output |
||||||
Measurement |
483 x 390 x 44 mm |
||||||
Weight |
5.8 KG |
7.5 KG |
8.5 KG |
9.8 KG |
10.6 KG |
12 KG |
|
First Packing: Plastic Bag (to prevent it from scratch);
Second Packing: Foam Packing (Anti Vibration or serious shock in transportation)
Third Packing: Carton Box (For easier delivery and selling)
| Product Quality Level | High & Medium Quality Provided |
| Price & Cost | Low price, low profit |
| Service | 7x24 online, OEM/ODM cooperation |
