Home > Products > Industrial - Electrical Product > Factory direct sales stabilizer voltage 20kva 20kw stabilizer with 3 years warrantly
Factory direct sales stabilizer voltage 20kva 20kw stabilizer with 3 years warrantly
- 1000 Set / Sets per Month
- shanghai/ningbo
- T/T L/C D/P D/A Credit Card
Product Details
Brand Name: | CHENF | Model Number: | SVC-20KW | Usage: | SVC |
Phase: | Single Phase | Current Type: | AC |
Product Description
Specifications
1)20kw voltage stabilizer 2)Input:160-270V Output:220V 3)Certificate:CE,ISO9001 4)5-7 days,Fast deliver
SVC single phase high accuracy full automatic AC voltage stabilizer
1)20kw voltage stabilizer
2)Input Voltage:160-270V Output Voltage:110V/220V 3)Quick Starting
4)Certificate:CE,ISO9001 5)Fast delivery,3years warranty
1. Product Introduction
SVC (TND/TNS) series servo motor automatic voltage stabilizer is the first generation of voltage stabilizer and made of contact type self-coupling voltage regulator, servo motor and automatic control circuit, etc. When the network voltage is unstable or the load change, the automatic sampling control circuit sends a signal to drive the servo motor to adjust the contact type self-coupling voltage regulator's carbon brush position, which finally make the output voltage regulated to the rated value and be stable. The overvoltage, undervoltage and delay protection can be added as per your requirement.
2. Technical parameter
Power Range: 0.5KVA-50KVA (single phase)
Input Voltage: Ordinary 160-250V, or optional larger range
Output Voltage: Ordinary 220V and 110V (Power: 500VA-5000VA), 220V (Power: 7.5KVA-50KVA)
Output Accuracy: 220V±3%, 110V±5%
Coil Material:
Ordinary aluminum and copper mixed, full copper can be customized, please let us know when your place order
Power Range: 1.5KVA-60KVA (three phase)
Input Voltage: Ordinary 277-430V, or optional larger range
Output Voltage: 380V±3%
Special input and output center voltage, like 3 phase 220v, 400v, 415v, etc, can be customized
Coil Material:
Ordinary compensation transformer aluminum and adjusting transformer copper, full copper can be customized
Display: Ordinary meter type, LED or LCD display screen can be customized, please let us know when your place order
Frequency: 50Hz/60Hz
Adjusting Time: <1s
Adjusting Speed: >15V/s
Waveform Distortion: Do not produce additional waveform distortion (static)
Efficiency: >95%
Relative Humidity: ≤95%
Ambient Temperature: -10 ~ +40°C
Dielectric Strength: 1500V/min
Insulation Resistance: ≥5MΩ
3.Features And Benefits
Small Size; Light Weight; Easy To Use
Very Low Price
Protect your home appliances everyday, such as TV, Refrigerator, Elevator, Air Conditioner, etc
1.SVC-10kw voltage regulator
2.Super quality
3.Competitive price
4.Extensive sales channels
