Features
- Rack mount amplifier in 2U size
- Rated power from 800W, 1000W, 1200W, 1500W to 2000W
- 70V, 100V and 4-16ohm speaker outputs
- Isolated transformer for human safety operation
- XLR line input and unbalanced 1/4 inch TRS phone jack line input
- line output feeds to another power amplifier
- Reliable protection of over heat, over load, clip & short circuit
- LED Indicators for power, signal, clip, protection and temp
- Excellent cooling fan ensures working effectively
Description
The Public Address Power Amplifier PPA-E1800 / PPA-E1010 / PPA-E1012 / PPA-E1015 / PPA-E1020 is designed in high reliability and efficiency, have power rating from 240W to 2000W. They are featured of line input, line output, provides speaker output at 4-16 ohm, 70V, 100V. It work efficient to extend power of pa system, reliable for medium or large sound system.
Application and Use Places
ARTONE Power Amplifier (Booster Amplifier) PPA-E1800 / PPA-E1010 / PPA-E1012 / PPA-E1015 / PPA-E1020 is ideal to use in commercial places like shopping mall, super markets, office building, school, stage performance, hotel, hospital, airport, bus or train stations which is larger than 200 square meter, sufficient use for background music and give speech.
The PPA-E1800 / PPA-E1010 / PPA-E1012 / PPA-E1015 / PPA-E1020 power amplifier works excellent in commercial sound system, reliable for sound amplifier and power extension, easy and quick to connect a medium or large pa system for your project, fulfill the space with music and announcement.
Specification
| Model No. | PPA-E1800 / PPA-E1010 / PPA-E1012 / PPA-E1015 / PPA-E1020 |
| Power and Power Tap | 800W/1000W/1200W/1500W/2000W |
| Speaker Outputs | 4-16 ohm, 70V, 100V |
| Input Sensitivity | Balanced XLR & unbalanced 6.3mm phone jack input |
| Output Sensitivity & Impedance | 300mV/600Ω, Unbalanced RCA output |
| Frequency Response | 70-18KHz |
| S/N Ratio | Mic:66dB / AUX:80dB |
| THD | Less than 0.1% at 1KHz, 1/3 rated power |
| Audio Source | MP3 (USB) / FM Tuner, AUX input x 2 |
| Cooling Method | Fan cooling |
| Protection | High temp, overload & short-circuit |
| Power Supply | 220V-240V 50/60Hz or 110V |
| Power Consumption | 1200W/1500W/1600W/2000W/4000W |
| Material and Finish | Alu panel, steel case |
| Dimension | 485 x 464 x 132 mm |
| Weight | 25KG/26KG/30.8KG/32.2KG/33.5KG |
First Packing: Plastic Bag (to prevent it from scratch);
Second Packing: Foam Packing (Anti Vibration or serious shock in transportation)
Third Packing: Carton Box (For easier delivery and selling)
| Product Quality Level | High & Medium Quality Provided |
| Price & Cost | Low price, low profit |
| Service | 7x24 online, OEM/ODM cooperation |
