Good Quality and Better Price dc Magnetic Contactor

Yueqing Chenf Electric Co., Ltd.
Good Quality and Better Price dc Magnetic Contactor thumbnail-1
Good Quality and Better Price dc Magnetic Contactor photo-1
US$ 10 - 65 MOQ: 20 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Chenf
Model Number:
ZJ400
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai and NingBo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name Chenf
Model Number ZJ400
Electricity Type DC
Phase 3
Main Circuit Rating Voltage Other, 80
Main Circuit Rating Current Other, 100-200

Specifications

Good quality and better price dc magnetic contactor
1.The delivery is fast
2.High quality
3.The price is competitive

Apply to

dc magnetic contactor


This conatct is applicable for using in DC circuits and can be powered with battery or rectified power.They perform power switching functions for power switching operations of traction drives as well as pump motor and other electric vehicles

dc magnetic contactor

Good quality and better price dc magnetic contactor

dc magnetic contactor

Good quality and better price dc magnetic contactor

dc magnetic contactor

Good quality and better price dc magnetic contactor

dc magnetic contactor

Good quality and better price dc magnetic contactor

dc magnetic contactor

Good quality and better price dc magnetic contactor

Technical parameters

dc magnetic contactor

Model No.

ZJ400

Contact Arrangement

1H (SPST-NO)

Contact Material

AgCdO

Contact Rating(at Resistive load)

400A  80VDC

400A  250VAC

Max.Switching Voltage

80VDC , 250VAC

Max.Switching Power

100000VA

Endurance of Over Loading Current 7le/10S

2800A/10S

Coil Rated Voltage

12,24,48,60,120VDC,etc.

Pick-up Voltage

20-60% of coil rated voltage

Drop-out Voltage

20-60% of coil rated voltage

Contact Pressure Drop

At most 300mV when 100A

Insulation Resistance

Min.100MΩat 500VDC

Dielectric Strength

(Between Insulated Electric Parts)

1500VAC 50/60Hz (1 minute)

Operate Time

Max.50mSec

Release Time

Max.50mSec

Ambient Temperature

-25~+60C

The shocking for fixed point

(10-200)HZ Acceleration <=3.5g

Shocking

(60-100) time/minute Acceleration<=4g

Mechanical life

100,000 Operation (no load)

Electrical life

50,000 Operation (at rated load)

Configuration installation drawing

dc magnetic contactor

Good quality and better price dc magnetic contactor

dc magnetic contactor

Good quality and better price dc magnetic contactor

The scope of our sales

dc magnetic contactor

Good quality and better price dc magnetic contactor

dc magnetic contactor



Main Markets:

South America
Africa
Eastern Europe
Oceania
Central America
Eastern Asia
Southern Europe
Northern Europe
North America
Western Europe



Total Annual Sales Volume:

Above US$100 Million



Export Percentage:

91% - 100%

dc magnetic contactor

Similar products
