Home > Products > New Products > SQ95-01 Three-ball fisher
SQ95-01 Three-ball fisher
- 500 Piece / Pieces per Month
- Tianjin Shanghai
- T/T
Product Details
Place of Origin: | China | Brand Name: | sinotai | Model Number: | SQ95-01 |
Type: | Other, Reverse Circulation Junk Magnets | Machine Type: | Drilling Equipment | Certification: | API |
Material: | Stainless Steel | Processing Type: | Forging | Use: | Well Drilling |
Packaging Details
standard package
Product Description
Product Explanation:
1.Three-ball fisher is a special fishing tool which fishing sucker rod coupling or other shoulder of sucker rod in casing.
2.Three-ball fisher according to the position change of three balls in slant borehole to change the diameter size of public inscribed circle, thus the shoulder of sucker rod and coupling was allowed to pass. After the sucker rod with coupling or shoulder entering guide shoe, the coupling or shoulder push the steel ball rising along slanted hole. The inscribed circle is formed through three balls increase gradually. After coupling and shoulder passed three balls, three balls according to his dead weight fall after rise along slanted hole, near to the body of sucker rod.
3. Bring up drilling tool, the shoulder of sucker rod or the size of coupling is larger so that can not pass to press three balls, the three balls in slanted hole under the action of slanted hole, applying a clamp force in radial direction to the fish, thereby the fish is cached.
Product types and specifications:
Item | Type | Dimension | Connection | Regulate and specification | |
Catch size | Hole Size | ||||
1 | SQ95-01 | 95×305 | 2 3/8TBG | 5/8″,3/4″Shoulder of rod and collar | 41/2 |
2 | SQ95-02 | 95×305 | 2 3/8TBG | 7/8″,1″Shoulder of rod and collar | 41/2 |
3 | SQ102-01 | 102×305 | 2 3/8TBG | 5/8″,3/4″Shoulder of rod and collar | 5 |
4 | SQ102-02 | 102×305 | 2 3/8TBG | 7/8″,1″Shoulder of rod and collar | 5 |
5 | SQ114-01 | 114×305 | 2 7/8TBG | 5/8″,3/4″Shoulder of rod and collar | 5-1/2 |
6 | SQ114-02 | 114×305 | 2 7/8TBG | 7/8″,1″Shoulder of rod and collar | 5-1/2 |
7 | SQ140 | 140×320 | 3 1/2,4TBG | 5/8″,3/4″7/8″,1″Shoulder of rod and collar | 6-5/8 |
Company Profile
![](http://res.goldsupplier.com/3/1_100_31472_480_360.jpg)
As a professional supplier of OCTG, drilling equipment and workover service, Sinotai Petroleum Equipment Co., Ltd. lies in the production base of petroleum equipment and China's second largest oil field --Shengi Oilfield. Our company is a high-tech enterprise in Dongying City with business scope covering the sale, trading, post-sale service and technological development of a wide variety of petroleum equipment.
Besides OCTG, we provide our customers with other drilling and oil recovery equipment like fishing tools, cementing tools, workover rigs, pumping units and OCTG accessories.
The striving target of our company is "Prestige first, Quality supreme; The shortest delivery time, The lowest price, The best quality". Customers' needs are our first priority and customer satisfaction is the bottom line by which we measure our success.
Contact Us
- Sinotai Petroleum Equipment Co., Ltd.
- Contact nameHerish Kuo
- Phone86-546-8300512
- AddressNo. 107, Bldg. 45, Gaoerfu, Wanda, Dongcheng
-
