Home > Industrial Equipment & Components > Valve > Ball Valve > TR8-L6-D Hand-wheel Regulating-pressure Valve
TR8-L6-D Hand-wheel Regulating-pressure Valve
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Regulating
Pressure:
Medium Pressure
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Standard or Nonstandard
Standard
Structure
Regulating
Pressure
Medium Pressure
Power
Pneumatic
Material
Other, aluminum alloy die-casting
Temperature of Media
Low Temperature
Media
Oil
Place of Origin
China
Model Number
TR8-L6-D
Brand Name
SINOTAI
TR8-L6-D hand-wheel regulating-pressure valve
Features
1.High regulating pressure feature precision
2.Can regulate outlet pressure range with hand-wheel in 0o-270o :0---0.8MPa stepless control, and keep the fixed value.
Parameter
model |
TR8-L6-D |
diameter mm |
6 |
max pressure |
1.6MPa |
pressure range |
0---0.8MPa |
flow character |
0.05MPa |
pressure character |
0.02MPa |
leakage |
150Nml/min |
temperature |
-40---+60°C |
I.Symbol
II.Model code
III.Appearance and installing
