API 16C Choke & Kill Combination manifold
- 1000 Set / Sets per Month
- Shanghai port
- T/T L/C D/P D/A Credit Card
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | SINOTAI | |
| Type | Other, Combination manifold | Machine Type | Drilling Equipment | |
| Certification | API | Material | High Manganese Steel | |
| Processing Type | Casting | Use | Other, well logging |
standard or according to customer requirement
Product Description
Specifications
API 16C Choke & Kill Combination manifoldWorking pressure: 2000PSI~20000PSI
Nominal bore: 2 1/16"~ 4 1/16"
API 16C Choke & Kill Combination manifold
Combine choke function with kill function of manifold to save platform space.
Working pressure: 2000PSI~20000PSI
Nominal bore: 2 1/16” ~ 4 1/16”(46mm~103mm)
Working medium: oil, natural gas, mud
Working temperature: -46°C~121°C( class LU)
Line: API16C standard
No | Working temperature | Nominal diameter | Bypass diameter |
1 | 140Mpa(20000psi) | 103mm (4 1/16”) | 103mm (4 1/16”) |
2 | 105Mpa(15000osi) | 103mm (4 1/16”) | 103mm (4 1/16”) |
3 | 70Mpa(10000psi) | 78mm( 3 1/16”) | 78mm( 3 1/16”) |
4 | 35Mpa( 5000psi) | 80mm (3 1/8”), 52mm (2 1/16”) | 80mm (3 1/8”), 52mm (2 1/16”) |
5 | 21Mpa(3000psi) | 80mm (3 1/8”), 52mm (2 1/16”) | 80mm (3 1/8”), 52mm (2 1/16”) |
6 | 14Mpa(2000pai) | 80mm (3 1/8”), 52mm (2 1/16”) | 80mm (3 1/8”), 52mm (2 1/16”) |
