API 7K Pneumatic Spinning Wrench
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
sinotai
Model Number:
Q254-250
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai or others
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
API 8A Side Door Type Drill Pipe ElevatorNegotiableMOQ: 1 Set -
S - Shaped Ram BOPNegotiableMOQ: 1 Set
-
Theft Prevention Wellhead & X-mas TreeNegotiableMOQ: 1 Set
-
HOT!!! API Oilfield Manual Tongs Type BUS$ 2,000 - 3,500,000MOQ: 1 Set
-
HOT!!! API 7K Q3 1/2-13 3/8-75SB Manual TongsUS$ 2,000 - 3,500,000MOQ: 1 Set
Place of Origin
Shandong, China
Brand Name
sinotai
Model Number
Q254-250
Type
Other, spinning wrench
Machine Type
Drilling Equipment
Certification
API
Material
Carbon Steel
Processing Type
Casting
Use
Well Drilling
Specifications
spinning wrench:1.It meets to API Spec.7K
2.drive mode:pneumatic,hydraulic
3.Type:Q140-200,254-250
spinning wrench
- It meets to API Spec.7K"Specification for Drilling Equipment".
- The wrench is the best replacement of rotary rope or chain.
- It is applied for the menchanized spinning operation.The applicable range of pipe dia. is wide,and it can be freely adjusted whenever necessary.
- There are two configurations for clamping mechanism:air tyre and air cylinder.
- two driving and controlling style:pneumatic and hydraulic
Model |
Q140-200 |
Q254-250 |
Q254-300Y |
|
Drive mode |
Pneumatic driven |
Hydraulic driven |
||
Size range |
mm |
88.9-139.7 |
88.9-254 |
88.9-254 |
in |
31/2-51/2 |
31/2-10 |
31/2-10 |
|
Air pressure |
MPa |
0.5-0.9 |
0.5-0.9 |
|
psi |
72-130 |
72-130 |
|
|
Hydraulic pressure rating |
Mpa |
|
|
14 |
psi |
|
|
2000 |
|
Max.stall torque |
Nm |
2000 |
2500 |
3000 |
Ft.lbf |
1475 |
1840 |
2210 |
|
Speed |
RPM |
0-90 |
0-120 |
0-95 |
Air consumption |
m3/min |
10.3 |
15 |
|
ft3/min |
360 |
529 |
|
|
Flow |
LPM |
|
|
120-140 |
GPM |
|
|
32-37 |
|
Size |
mm |
1400*530*835 |
1250*570*465 |
1100*560*700 |
in |
55*21*33 |
49*23*18 |
44*23*28 |
|
Weight |
Kg |
378 |
440 |
400 |
lb |
833 |
970 |
880 |
|
