API 8A/A6C Kelly Spinner
US$ 5,000 - 10,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
sinotai
Model Number:
A6C
Payment & Shipping
Payment Methods:
Port of Shipment:
main ports
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Shandong, China
Brand Name
sinotai
Model Number
A6C
Type
Other, Kelly spinner
Machine Type
Drilling Equipment
Certification
API
Material
Other, alloy steel
Processing Type
Casting
Use
Well Drilling
Specifications
Kelly spinner:1.API Spec.8A.
2.seaurity,high efficiency and saving time.
3.air or hydraulic motor
Kelly spinner
- it conforms to API Spec.8A.
- It is a special equipment to connect single pipe by matching with mouse hole clamping device.
- Model:A6C,6600,6800
- It utilizes air or hydraulic motor to drive Kelly to rotate.
- There is the feature of seaurity,high efficiency and saving time.
Model |
A6C |
6600 |
6800 |
||
Drive mode |
Pneumatic driven |
Hydraulic driven |
|||
Max. static load |
2250kN |
||||
pressure |
MPa |
0.5-0.9 |
0.5-0.9 |
16 |
|
Psi |
72-130 |
72-130 |
2320 |
||
Stall torque |
Nm |
1500 |
1500 |
1650 |
|
Ft.lbf |
1100 |
1100 |
1215 |
||
Ldel speed |
RPM |
130 |
130 |
120 |
|
Rotating direction |
double |
||||
Air consumption/flow |
9.3 m3/min |
15 m3/min |
91 LPM |
||
330 ft3/min |
529 ft3/min |
24 GPM |
|||
Stem connection |
6-5/8 REG LH |
||||
size |
mm |
760*760*1220 |
740*710*978 |
740*710*978 |
|
in |
30*30*48 |
29*28*38.5 |
29*28*38.5 |
||
weight |
Kg |
540 |
500 |
504 |
|
lb |
1200 |
1100 |
1110 |
||
