Help CenterAPI 7K CUL Type Casing Bushing
Related Products
Specifications
1.Casing Bushing and insert bowls can handle casing from 95/8 -30 "2.Type CU and CUL are solid bushing,CB are split
3.API 7K
Casing Bushings
Type CU. CUL, CB and etc.
Casing Bushings and insert bowls can handle casing from 95/8 to 30 inch O.D.
Type CU and CUL are solid bushings; Type CB are split bushings.
Technical Specification:
Rotary Table Sizein |
Model |
Casing Sizein |
Casing Bushing & Insert Bowl |
17 1/2 or 20 1/2 |
CU |
113/4-133/8 |
Body 3102 |
95/8-103/4 |
Body 3102 w/ bowl 1902(No.2) |
||
27 1/2 |
CUL |
185/8-20 |
Body 3103 |
16 |
Body 3103 w/ bowl 3104(20*16) |
||
113/4-133/8 |
Body 3103 w/ bowl 3105(No.1) |
||
23/8-85/8 |
Body 3103 w/ bowl 1809(No.3) |
||
27 1/2 |
CB |
185/8-20 |
Body 6695 |
16 |
Body 6695 w/ bowl 6127(20*16) |
||
113/4-133/8 |
Body 6695 w/ bowl 6126(No.1) |
||
95/8-103/4 |
Body 6695 w/ bowl 6114(No.2) |
||
37 1/2 |
CB |
30 |
Body 30 |
26 |
Body 26 |
||
24 |
Body 24 |
||
185/8-20 |
Body 20 |
||
16 |
Body 20 w/ bowl 6127(20*16) |
||
113/4-133/8 |
Body 20 w/ bowl 6126(No.1) |
||
95/8-103/4 |
Body 20 w/ bowl 6114(N0.2) |
