Ball screw gate valves

Name: Ball screw gate valves
Brand: sinotai
Price: USD $100 - 2,000 / Set

FOB Price

USD $100 - $2,000 / Set

1 Set(Min.Order)

Supply Ability 3000 Set / Sets per Month
Port main ports of China
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Standard or Nonstandard:	Standard	Structure:	Control	Pressure:	Medium Pressure
Power:	Pneumatic	Material:	Casting	Temperature of Media:	Medium Temperature
Media:	Oil	Port Size:	5 1/8"	Place of Origin:	Shandong, China
Brand Name:	sinotai

Packaging Details

wooden case

Product Description

Specifications

1.5 1/8" 10000psi ball screwed gate valve
2. Flange Ends .RTJ
3.API6A standard
4.Alloy Steel material

Ball screw gate valves

Frac valves - ball screw gate valves provided by Sinotai is a type of large bore gate high pressure valve which were improved from Cameron FLS-R gate valve, it's the main component of frac tree, the frac valve is often used on the top of the wellhead on high pressure oil well, can do the frac job for isolating the fluid from the well.

We provides the FRAC VALVE was designed in accordance to API 6A and NACE MR-01-75, strict quality control conforming to ISO registration, This type of the frac valve contains flanged end, studded outlet, and special block body , both manual and hydraulic operation type can be supplied by SINOTAI, ball screw operation designed in manual type frac valve.

Features:
• Forged Body and Bonnet.
• Low operation torque under pressure.
• Metal to metal sealing gate-to-seat and the seat-to-body.
• Ball screw stem when manual operation.
• Bi-directional FLS-R style slab gate valve for high pressure
• Flanged & studded outlet are available.
• The stem packing is a pressure energized seal and can resist severe Temp. and fluids.
• Critical application from 10000 psi to 20000 psi pressure.
