S-Shaped Mannual Ram BOP API16A

Name: S-Shaped Mannual Ram BOP API16A
Brand: Sinotai
SKU: 119563033

US$ 5,000 - 20,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Shandong, China

Brand Name:

Sinotai

Sinotai Petroleum Equipment Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

tianjin qingdao shanghai etc

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Shandong, China

Brand Name Sinotai

Model Number S type

Certification API 16A

Warranty 18 months

After-sales Service Provided Engineers available to service machinery overseas

Structure Features:

- Body and side door are made of alloy steel;

- Use seal rings assembly to improve sealing of side door;

- Use floating type ram. Front ram rubber is separated from top ram rubber, making it more reliable in sealing and easier to change;

- Use buried oil way inside body. Loading hinge is separated from hydraulic hinge;

- Compact hinge structure makes it easy to assemble and disassemble;

- Use arc-shaped body chamber with four round corners as transition section to reduce stress peak value whenever bearing the pressure;

- Ram cavity can be fitted with ram assembly of same type BOP made abroad;

-Flange grooves are stainless steel lined.

S-Shaped Ram BOP

Type S BOP Operation data

Drift diameter/pressure	Oil quantity for opening the ram(L/set)	Oil quantity for closing the ram(L/set)	Locking mode	Piston diameter(mm)	Remarks
7 1/16” / 5000psi	1.6	1.9	Manual	150
7 1/16” / 10000psi	2.22	2.5	Manual	180
7 1/16” / 15000psi	7.48	85	Manual	280	Allowed to be fitted with a shear ram
9” /3000psi	1.55	1.9	Manual	140
9” / 5000psi	4.7	5.3	Manual	220
11” / 3000psi	2.68	3.22	Manual	165
11” / 5000psi	5.2	5.45	Manual	220
11” / 5000psi	14.6	16.3	Manual	355	Allowed to be fitted with a shear ram
11” /10000psi	6.6	7.4	Manual	250
11” / 15000psi	14.4	16.7	Manual	355	Allowed to be fitted with a shear ram
13 5/8” /5000psi	7.4	8.3	Manual	250	Allowed to be fitted with a shear ram
13 5/8” /10000psi	19.9	20	Manual	355	Allowed to be fitted with a shear ram
13 5/8” / 15000psi	17.44	19	Manual	355	Allowed to be fitted with a shear ram
20 3/4” / 3000psi	12.2	13.6	Manual	250
21 1/4”/ 2000psi	13.2	15.4	Manual	250
