Centrifuge
Main feature:
LW centrifuge is driven by two motors.
The main motor drives the drum and the outer casing of differential through belts while the auxiliary motor, after the differential shifting speed, drives the spiral propeller.
This will make the drum and the spiral propeller rotate inthe same direction with a certain differential speed.
Technical Parameters:
Model |
LWF450*842N |
LWF450*1000N |
GLW355*1250N |
GLW355*1250 |
Bowl Diameter |
450mm |
450mm |
355mm |
355mm |
Rotary Speed |
1800r/min |
1800r/min |
3200r/min |
0~3200r/min |
G-Force |
815 |
815 |
2035 |
2035 |
Separation point |
5~7μm |
5~7μm |
2~5μm |
2~5μm |
Main Drive |
22kw-4p |
30kw-4p |
30kw-4p |
37kw-4p |
Back Drive |
5.5kw-4p |
7.5kw-4p |
7.5kw-4p |
7.5kw-4p |
Max capacity |
≤40m3/h |
≤60m3/h |
≤40m3/h |
≤40m3/h |
Weight |
2550kg |
2700kg |
2950kg |
3000kg |
0mm |
Seaworthy packing
