Specifications
1.Poor Boy Degasser2. ZYQ series
3. normal pressure & pressure auto-control
Specifications
Oilfield Mud Gas Separator
1.simple structure
2.big disposal capacity
3.high degassing efficiency
4.long service life
Mud gas separator
1. Mud gas separator(Poor Boy Degasser) is professional equipment to treat the gas invade mud.
2. When the drilling mud result gas invade, the proportion of its weight and viscosity have a greater deviation not to
meet the requirements of drilling. The serious situation is that would cause Chung well, and even blowout accident
occurred, if not to treat it timely.
3. It is divided into the normal pressure Mud gas separator and pressure auto-control Mud gas separator, according to the pressure.
4. ZYQ series Mud gas Separator combined with the electric ignition devicecan be used to ensure the drilling process smooth.
ZYQ series Mud gas separator Technical Parameters
Model |
ZYQ800 |
ZYQ1000 |
ZYQ1200 |
Main body diameter |
800mm |
1000mm |
1200mm |
Capacity |
180~260m3/h |
240~320m3/h |
260~380m3/h |
Inlet pipe |
5" |
5" |
5" |
Output pipe |
6" |
8" |
10" |
Gas discharge pipe |
6" |
8" |
8" |
Weight |
1600kg |
2000kg |
2000kg |
Dimensions |
1900×1900×5700mm |
2000×2000×5860mm |
2200×2200×6634mm |
