CG801 weight indicator
Altogether there are 16 versions of JZ Series Weight indicating Systems ranging from 500 tons to 40 tons for different types of drilling / workover rigs.
Each set of weight indicating system is composed of a JZG deadline anchor, a JZ weight indicator and a JZJ recorder.
It features high accuracy and excellent reliability;
It is strongly corrosion-resistant,Anticorrosive escape-ment device adapts well to the working environment on the sea;
The dual-system (metric and imperial) secondary instrument can be used not only in China but also in other countries;
As quick self-sealing connectors are used, connection between hoses can be realized in a fast, convenient and reliable manner;
Working curves recorded with ink facilitates creation of drilling files.
Weight indicator parameters:
Type |
Anchor Type |
Form of Primary Instrument |
Max.Deadline load(kN) |
Number of Lines |
Load(kN) |
JZ900 |
JZG72 |
Horizontal |
720 |
14 |
10080 |
JZ700 |
JZG60 |
Vertical |
600 |
14 |
8400 |
JZ500 |
JZG42 |
Vertical |
420 |
12 |
5040 |
JZ500A |
JZG41 |
Horizontal |
410 |
12 |
4920 |
JZ400 |
JZG35 |
Vertical |
350 |
12 |
4200 |
JZ400B |
JZG34A |
Horizontal |
340 |
12 |
4080 |
JZ250 |
JZG24 |
Vertical |
240 |
12 |
2880 |
JZ200 |
JZG20 |
Horizontal |
200 |
10 |
2000 |
JZ150A |
JZG18A |
Vertical |
180 |
10 |
1800 |
JZ150 |
JZG18 |
Horizontal |
180 |
10* |
1800 |
JZ100 |
JZG15 |
Horizontal |
150 |
10 |
1500 |
JZ60 |
JZG10 |
Straight pull |
100 |
8 |
800 |
JZ40 |
JZG10A |
Horizontal |
100 |
6 |
600 |
JZ82 |
JZG13 |
Straight pull |
136.6 |
6 |
820 |
JZ75 |
JZG12 |
Straight pull |
125 |
6 |
750 |
