Oilfield SGH2000L Well Echometer With Gas Sounder &dynamometer Test Function

Name: Oilfield SGH2000L Well Echometer With Gas Sounder &dynamometer Test Function
Brand: Sinotai
Availability: InStock

FOB Price

US$ 500 - 2,000 / Set

300 Sets(Min. Order)

Port Tianjin Shanghai Qingda etc
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China		Brand Name	Sinotai
Model Number	SGH2000		Usage	Other, well drilling tester

Packaging Details

according to the requirement

Product Description

Specifications

SGH2000 Pumping Well Tester
1.check liquid level
asure electric current diagram
3.paper tapes
4.displayed on LCD

SGH2000 Pumping Well Tester

Application Areas

SGH2000 Pumping Well Tester is mainly used to check liquid level, dynamometer diagram of pumping well, and leakage loss of valve. It can also be used to measure electric current diagram and casing pressure if necessary.

Features

Equipped with automatic timer and person-machine interaction interface.

Wireless dynamometer test and infrared optical code displacement test.

Test results are recorded by paper tapes, displayed on LCD and tracked by graphic curves at real time.

Plays at real-time liquid level and dynamometer diagram on LCD screen, and saves the testing results.

On-line data calibration , USB data communication.

Directly drive printer (Epson) to out print tested data.

Various load sensors (Shutdown type, non-shutdown type) and wellhead connectors(gas sounoler, bulet sounder)for you to choose.

Technical Specifications

Measurable liquid depth:

Casing pressure≤0.5MPa,Maxst measurable level: 3000m

Casing pressure>0.5MPa,Maxst measurable level: 3500m

The chart running speed of the secondary instrument: 100±0.5mm/s

The instability of chart running of the secondary instrument: ±0.2%

Capacity of curves storage:120 dynamometer diagrams and 100 liquid level curves

Load range: 0~140kN Accuracy: ±1%F.S(shutdown type)

0~50kN 0~80kN 0~140kN

Accuracy: ±3%F.S(non-shutdown type)

Displacement: 0~8m Accuracy: ±1%F.S

Distance limit of radio transmission of dynamometer diagrams: 30m

Working temperature: -30~55°C

Dimensions and weights

Primary instrument(non-shatdown type) 200×85×65mm 2.5kg

Secondary instrument 380×260×140mm 9.5kg
