Help CenterTRUCK V BELT FAN BELT/ KOMATSU BELT/COMMINS PK BELT
Related Products
-
Poly v BeltUS$ 0.3 - 0.5MOQ: 200 Meters -
High Quality V Belt For Washing Machine V Belt Manufacturer V Belt PriceNegotiableMOQ: 200 Meters
-
V Belt Cotton Canvas Carcase Conveyor Rubber Belt for Coal Washing Industry by CE/ISO Largest ManufacturerNegotiableMOQ: 200 Meters
-
V Belt Production Line Using for Cement, Fertilizer and Mining IndustryNegotiableMOQ: 200 Meters
-
High Strength Nylon Rubber Conveyor Belt for Quarries and Sandpits With Good PriceNegotiableMOQ: 100 Meters
Specifications
v belt 1.high strength,2.wear resistance,
3.low elongation,
4.impact-resistant transient,
5.lasting durability
1.high strength,
2.wear resistance,
3.low elongation,
4.impact-resistant transient,
5.lasting durability
Structure: Wrapped v belt/classical v-belt is made up of wrapping layer , stretching layer , strength layer and compression layer . it has excellent features of heat-resistance . wear proof , ageing- resistance and fatigue resistance , etc.
Using: Wrapped v belt/classical v-belt is used widely in power transmission of mechanical equipments driven by electric motors and diesel engines.
Wrapped v belt/classical v-belt Size:
|
Production Type |
Top Width |
Pitch Width |
Height |
Angle |
Length range |
O(Z) |
10 |
8.5 |
6 |
40° |
450mm-2500mm |
A |
13 |
11.0 |
8 |
40° |
500mm-3550 |
B |
17 |
14.0 |
11 |
40° |
600mm-6400mm |
C |
22 |
19.0 |
14 |
40° |
1180mm-1200mm |
D |
32 |
27.0 |
19 |
40° |
2200mm-1400mm |
E |
38 |
32.0 |
23 |
40° |
3000mm-16000mm |
Wrapped v belt/classical v-belt Physical Characters Of Common V-belt(wrapped)GB/T1171-2006
|
Type |
Tensile-Strength KN ≥ |
Reference Force Extension %≤ |
Adhesive Strength Of The Cord (KN/m)≥ |
Adhesive Strength Between Cloth And Top Rubber(KN/m)≥ |
Z |
2.0 |
7.0 |
13.0 |
- |
A |
3.0 |
17.0 |
||
B |
5.0 |
21.0 |
2.0 |
|
C |
9.0 |
31.0 |
||
D |
15.0 |
31.0 |
||
E |
20.0 |
31.0 |
Wrapped v belt/classical v-belt Store And Transport
1.In storage and transportation of V-belt ,direct sunshine as well as the soaking of rain of rain and snow should be kept clean and the contact with acid,alkali,oil and organic solutions should be prevented.Cares should be taken to prevent mechanical damage.And,the belt should be 1 Km away from heat radiation devices.
2.The storage temperature should be -18--+40.
3.In storage,the belt should no be under heavy pressure so as to prevent deformation.The best method is to hang the belt on a crescent frame or put it on the shelt flatly.
4.The performance will be kept unchanged in one year when the belt is in storage under the above condition.
