Drilling Mud Pump,3NB Series, API Standard

Sinotai Petroleum Equipment Co., Ltd.
5Yrs
Drilling Mud Pump,3NB Series, API Standard thumbnail-1
Drilling Mud Pump,3NB Series, API Standard photo-1
US$ 10,000 - 200,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, 3NB Mud Pump, Triplex
Power Type:
Diesel
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai / Tianjin Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, 3NB Mud Pump, Triplex
Power Type Diesel
Place of Origin China
Brand Name SINOTAI
Model Number 3NB
Usage Other, oil well
Certification API
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.NB-350,NB-500,NB-600,NB-800
2.Reliable to lubricate and promote the service life of power end
3.according to SY5138 standard

3NB mud pump

 Drilling Mud Pump,3NB series, API standardDrilling Mud Pump,3NB series, API standardDrilling Mud Pump,3NB series, API standard

  1. This series mud pumps are strictly manufactured according

    to SY5138 standard of CNPC and are tested accordingly when

    leave factory.

  2. Reliable to lubricate and promote the service life of power end.

Model

3NB-350

3NB-500

3NB-600

3NB-800

Type

Triplex

Triplex

Triplex

Triplex

Input Power

257kw/350HP

368kw/500HP

441kw/500HP

588kw/800HP

Rated Speed

130

120

135

130

Stroke(mm)

180

180

196

274

Max.Liner Dia.(mm)

160

170

180

180

Suction Inlet(mm)

203

200

200

254

Discharge Inlet(mm)

76

83

101

101

Gear Ration

4.483

4.696

4.696

3.482

Drive Shaft Speed

582.8

563.52

633.96

435.25

Overall Size(mm3)

3600*2080*2015

3600*2280*2080

3900*2285*2085

4600*2155*2052

Weight(kg)

8058

9484

11000

17200

Model

3NB-1000

3NB-1300

3NB-1600

3NB-2200

Type

Triplex

Triplex

Triplex

Triplex

Input Power

735kw/1000HP

955kw/1300HP

1176kw/1600HP

1640kw/2200HP

Rated Speed

125

120

120

105

Stroke(mm)

274

305

305

356

Max.Liner Dia.(mm)

180

190

190

230

Suction Inlet(mm)

254

305

305

305

Discharge Inlet(mm)

101

101

101

130

Gear Ration

3.482

3.657

3.657

3.152

Drive Shaft Speed

435.25

438.84

438.84

369

Overall Size(mm3)

4600*2155*2052

5250*2450*2625

4720*2822*2660

6000*2950*3250

Weight(kg)

18000

23000

27100

38800
