Specifications
1Type:casing slips2Inch:6 5/8 to 30 inch(168.3-762mm)
3Max.Load tons:(250-1125)
4.good before and after service
Casing Slips
Casing Slips are made up of body segments of the same sizes linked up by Hinge Pins.Adding or reducing body segments and changing button inserts according to the specification can suit different sizes of casings pipes.The button inserts can be used in both Casing Slips and Drilling Collar Slips.Eight different kinds of button inserts will satisify all needs.
1.Casing Slips can accommodate casing from 6 5/8 to 30 inch (168.3-762mm) O.D.
2.Full range of Replacement Part
3.The datails are as bellow:
Casing OD. |
in |
4½ |
4¾ |
5 |
5½ |
5¾ |
6 |
6 |
7 |
7 |
8 |
||||||||||
mm |
114.3 |
120.7 |
127 |
139.7 |
146.1 |
152.4 |
168.3 |
177.8 |
193.7 |
219.1 |
|||||||||||
Weight |
Kg |
72 |
72 |
72 |
70 |
70 |
70 |
93 |
88 |
79 |
86 |
||||||||||
lb |
151.2 |
151.2 |
151.2 |
147 |
147 |
147 |
195.3 |
184.8 |
165.9 |
180.6 |
|||||||||||
Insert bowl No. |
API or No. 3 |
||||||||||||||||||||
Casing OD |
in |
9 |
10¾ |
11¾ |
13 |
16 |
18 |
20 |
24 |
26 |
30 |
||||||||||
mm |
244.5 |
273.1 |
298.5 |
339.7 |
406.4 |
473.1 |
508 |
609.6 |
660.4 |
762 |
|||||||||||
Weight |
Kg |
105 |
110 |
136 |
135 |
158 |
185 |
192 |
219 |
238 |
262 |
||||||||||
lb |
220.5 |
231 |
285.6 |
283.5 |
331.8 |
388.5 |
403.2 |
459.9 |
499.8 |
550.2 |
|||||||||||
Insert bowl No. |
No. 2 |
No. 1 |
Matching Casing Bushing |
||||||||||||||||||
