ZJ30 drilling rig rotary table-ZP175/205/275/375/495
- 50 Set / Sets per Month
- Tianjin new port Shanghai
- T/T Credit Card
Product Details
Place of Origin: | Shandong, China | Brand Name: | Sinotai | Model Number: | ZP175/205/275/375/495 |
Type: | Rotary Table | Machine Type: | Drilling Equipment | Certification: | API |
Material: | Iron | Processing Type: | Forging | Use: | Well Drilling |
Packaging Details
Intetnational Standard Packing 20feet container size: 5.69M * 2.13M * 2.18M,Gw:17.5Ton, Volume24-26m3 40feet container size: 11.8M * 2.13M * 2.18M,Gw:22Ton, Volume54m3 40feet high container size: 11.8M * 2.13M * 2.72M,Gw:22ton, Volume68m3 45feet high container size: 13.58M * 2.34M * 2.71M,Gw:29ton, Volume86m3
Product Description
Specifications
nform to API Spec 7K
2.applicable to API monogram
3.alloy steel gears
fessional machining and heat treatment
Main features of the rotary table:
1. Gear wheel and pinions are all made of alloy steel.
2. According to needs, master bushing and kelly roller bushing can adopt square drive or pin drive.
3. Pin drive type master bushing can put into API standard kelly or hex kelly roller bushing. Long clips and short clips are applicable.
4. Full lubrication and steady seal.
5. The rotary table and API monogram can be used.
Rotary table
The main technical performance and specification for the rotary table:
Model | ZP175 | ZP205 | ZP205-II | ZP275 | ZP375 | ZP495 | |
Opening Dia. | mm(in) | 444.5(17-1/2) | 520.7(20-1/2) | 520.7(20-1/2) | 698.5(27-1/2) | 952.5(37-1/2) | 1257.3(49-1/2) |
Center of Table to Center of Sprocket | mm(in) | 1118(44) | 1353(53-1/4) | 1118(44) | 1353(53-1/4) | 1353(53-1/4) | 1651(65) |
Max. Static Load | KN (US Ton) | 2700(300) | 3150(350) | 3150(350) | 4540(500) | 5850(650) | 7250(800) |
Max. Working Torque | NM (ft-lbs) | 13729(10124.6) | 22555(16633.5) | 22555(16633.5) | 27459(16633.5) | 32362(23865.8) | 37000(27286.18) |
Max. Speed | r/min | 350 | 300 | 300 | 300 | 300 | 300 |
Gear Ratio | 3.75 | 3.22 | 3.79 | 3.67 | 3.56 | 3.93 | |
Overall Dimension (LxWxH) | mm(in) | 1974x1366x560 (77.7x53.8x22) | 2217×1500×660 (87.3×59 ×26) | 1969×1410×610 (77.5×55.5×24) | 2392×1670×685 (94.2×65.7×27) | 2468×1810×718 (97.2×71.3×28.3) | 2940×2184×813 (115.7×86×32) |
Weight | kg(lbs) | 3666.5(8083) | 5500(12125) | 5450(12015) | 6122(13496) | 7970(17570) | 11626(25630.9) |
Company Profile
As a professional supplier of OCTG, drilling equipment and workover service, Sinotai Petroleum Equipment Co., Ltd. lies in the production base of petroleum equipment and China's second largest oil field --Shengi Oilfield. Our company is a high-tech enterprise in Dongying City with business scope covering the sale, trading, post-sale service and technological development of a wide variety of petroleum equipment.
Besides OCTG, we provide our customers with other drilling and oil recovery equipment like fishing tools, cementing tools, workover rigs, pumping units and OCTG accessories.
The striving target of our company is "Prestige first, Quality supreme; The shortest delivery time, The lowest price, The best quality". Customers' needs are our first priority and customer satisfaction is the bottom line by which we measure our success.
