Help CenterHTB17 AC Motor for Drilling Pump
Related Products
Specifications
1.Great torque2.Mall size, light weight
3.High efficiency
4.Maintenance-free
5.High reliability
HTB17 AC motor for drilling pump
[ Offshore Drilling Module - Component ]
Product Explanation:This engine is a three-phase squirrel-cage induction motor researched to support the 5NB1600G drilling pump group, which is used to directly drive the crankshaft and put the piston to work.
The engine is designed in accordance with the increased safety explosion-proof requirements , the main features are: wide range of speed control by constant power, strong overload capacity, maintenance-free, high efficiency and high reliability.
Product types and specifications:
Power rating |
1200 kW |
|
Voltage rating |
575V |
|
Current rating |
1504 A |
|
Torque rating |
25529 N·m |
|
Rated revolution |
449 r/min |
|
Rated frequency |
30.5 Hz |
|
Power factor |
0.85 |
|
efficiency |
95% |
|
Constant power Max speed |
623 r/min |
|
Maximum constant frequency |
42.5 Hz |
|
Insulation class |
H |
|
Connection mode |
Y |
|
Work characters |
S1 |
|
Protection level |
Main engineIP44,connecting boxIP55 |
|
Cooling method |
Forced ventilation( with wind pressure testing switch) |
|
Cooling draught fan |
Explosion-proof type three-phase asynchronous motor22kW,380V,50Hz,ExdⅡBT4 |
|
Heater |
AC220V,200W,ExeⅡT4 |
|
Weight |
6120kg |
|
