Help Center3ZB-3ZB-670 Horizontal Single Acting Triplex Plunger Pump
Related Products
Specifications
3ZB-670 horizontal single acting triplex plunger pumpConsist of power end, gear reducer and fluid end
Forged of alloy steel
3ZB-670 horizontal single acting triplex plunger pump
3ZB-670 horizontal single acting triplex plunger pump mainly consists of power end, gear reducer and fluid end.
Gear reducer can be installed on the left or right including seventeen (17) different installation positions, which is featured with flexible installation position, easy maintenance, etc.
Fluid end is forged of quality alloy steel and fabricated by machining center with various plunger sizes.
The pump is the optimized choice for HP cementing unit, featured by good quality, large power, high pressure, small size, light weight, etc.
Model |
3ZB-670 |
Max braking HP(kW) |
900(670) |
Max load,connecting rod lbf(kN) |
119700(532) |
Stroke mm |
203.2(8″) |
Gear ratio |
5.619:1 |
L×W×H (mm) |
79.21″×55.51″×40″(2012×1410×1016) |
Weight lbs(kg) |
9000(4082) |
