Home > Products > Drilling Rig Accessories > XSL Hydraulic Spinner Swivel
XSL Hydraulic Spinner Swivel
- main ports
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | SINOTAI | |
| Model Number | XSL | Type | Other, SWIVEL | |
| Machine Type | Drilling Equipment | Certification | API | |
| Material | Other, aloy steel | Processing Type | Casting | |
| Use | Well Drilling |
plywood case
Product Description
Specifications
hydraulic spinner swivel:1.itstandard: API Spec. 8A&4F
2.equipped with pneumatic motor or hydraulic
hydraulic spinner swivel
- The swivel conforms to API Spec. 8A&4F
- Type:XSL90,XSL135,XSL225,XSL450,XSL585
- The swivel is equipped with pneumatic motor for a convenient shackle operation.
- The grooveneck can be connected with a pipe directly by a transition sub.
Model | SL90 | SL135 | SL225 | SL450 | SL585 | |
Max. static load rating KN | 900 | 1350 | 2250 | 4500 | 5850 | |
Max. speed r/min | 300 | 300 | 300 | 300 | 300 | |
Max. working pressure Mpa(psi) | 25(3570) | 35(5000) | 35(5000) | 35(5000) | 35(5000) | |
Hook clearance over gooseneck mm(in) | 435(17 1/8) | 495(19 1/2) | 540(21 5/8) | 549(21 5/8)
| 584(23) | |
Central pipe over groovesneck mm(in) | 64(2 1/2) | 64(2 1/2) | 75(3) | 75(3) | 75(3) | |
Coupling thread | To stem | 4 1/2” | 4 1/2” | 6 5/8” | 7 5/8” | 7 5/8” |
To Kelly | 6 5/8” | 6 5/8” | 6 5/8” | 6 5/8” | 6 5/8” | |
XSL Swivel
