Grey Color Plastic Ppr Pipe
- NINGBO
- T/T Money Gram Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | wanjiayou | |
| Model Number | WJY-PPR-P05 | Material | Other, PP-R | |
| Specification | 20mm-110mm | Length | 4m/pc | |
| Thickness | 2.0-10.0mm | Standard | ISO |
Product Description
——Product Introduction——
In cold and hot water transprotation project, the PPR pipes and fitttings adopts advanced fusion technology ,whoes technical performance and economical indicator are better than other similar pipes,n particular, its excellent health performance, from production to the whole process of recycling waste can achieve high health and environmental protection requirements.
——Product Features——
1) High Temperature Resistance: the maximum sustained working temperature is up to 70 ºC , the maximum transient temperature is up to 95 ºC
2 )Heat Preservation: low thermal conductivity which is only 1/1500 of brass pipe, and 1/250 of steel pipe
3) Non-toxic: no heavy metal additives, would not be covered with dirt or contaminated by bacterium
4) Corrosion Resistant: resist chemical matters or electron chemical corrosion
5) Lower Installation Costs: light weight and ease of installation can reduce installation costs by as much as 50% over metal piping system
6) Higher Flow Capacity: smooth interior walls result in lower pressure loss and higher volume than metal pipes
7) Long Life: more than 50 years under normal conditions
8) Recycled and Environment-friendly
——Product Specification——
Outer Diameter | PP-R Water Supply Pipe | ||||||||
PN 1.0MPa (cold water) | PN 1.6MPa (cold water) | PN 2.0MPa (hot water) | PN 2.5MPa (hot water) |
|
|
|
|
| |
Wall Thickness |
|
|
|
|
| ||||
20 | 2.0 | 2.3 | 2.8 | 3.4 |
|
|
|
|
|
25 | 2.3 | 2.8 | 3.5 | 4.2 |
|
|
|
|
|
32 | 3.0 | 3.6 | 4.4 | 5.4 |
|
|
|
|
|
40 | 3.7 | 4.5 | 5.5 | 6.7 |
|
|
|
|
|
50 | 4.6 | 5.6 | 6.9 | 8.3 |
|
|
|
|
|
63 | 5.8 | 7.1 | 8.7 | 10.5 |
|
|
|
|
|
75 | 6.9 | 8.4 | 10.1 | 12.3 |
|
|
|
|
|
90 | 8.2 | 10.1 | 12.3 | 15.1 |
|
|
|
|
|
110 | 10.0 | 12.3 | 15.1 | 18.3 |
|
|
|
|
|
——Application area——
1) Pipe for hot and cold water,drinking water system
2) Pipe for heating ,floor and wall warming system, melting snow in north building
3) Pipe for solar heating system ,hot and cold device
4) Pipe for transproting oil and coling liquid
5) Pipe for air contaditioning external connecting
6) Pipe for transporting oxygen in hospital
——Product Photos——
——Sales Service——
Packaging :roll plastic bag for pipe ,put fittings into nylon bags then out of carton
Shipping:For samples order ,we support transfer by international express,such as FEDEX,DHL,TNT or EMS;
For final order,we do sea shipping ,our factory are near from shanghai port and ningbo port ,we can transfer goods to port within 6 hours
Delivery : Within 15-30 days after receiving deposit
We promise our customers the Best-Quality products with reasonable price.
Q: What the Raw material ?
A: We only use 100% Korea material.
Q: What is your MOQ?
A: As customer's request. ( For example :PPR pipe D20, MOQ 3000m)
Q: What is the production ability ? or delivery time ?
A: Our production ability support 40HQ order finish in one week.
Q: What is the regular shipping port ?
A: Shanghai or Ningbo
Q: What is your payment ?
A: Advance payment or TT before shipping or LC
Q: Can we have sample ?
A: Sample free, freight free in China any place. Overseas freight cost you.
Q: For urgently doubuts, who online ?
A: Sales and marketing Manager 24 hours online service.
If you have any questions, Kindly please feel free to contact us.
Contact : Jimmy zheng— Sales & Marketing Manager
Tel:86-0576-83172155
Mob: 86-15268865202
Trademanager: wjypipes
Skype: jimmyzheng1989
QQ: 121724545
