Hot Seal Gas Filling Machine Made in China 3500*800*1700
US$ 2000.00 - 3000.00
MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Application:
Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Textiles, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles
Packaging Type:
Bags, Barrel, Bottles, Cans, Capsule, Cartons, Case, Pouch, Stand-up Pouch
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China Supplier Water Bottle Filling Machine 1550*800*1230mmUS$ 2000.00 - 3000.00MOQ: 1 Piece -
China Plastic Tube Filling and Sealing MachineUS$ 2000.00 - 3000.00MOQ: 1 Piece
-
Made in China Milk Bottle Filling MachineUS$ 2000.00 - 3000.00MOQ: 1 Piece
-
Hot Seal Bag in Box Filling Machine Made in ChinaUS$ 2000.00 - 3000.00MOQ: 1 Piece
-
Paste Filling Machine China WholesaleUS$ 2000.00 - 3000.00MOQ: 1 Piece
Condition
New
Application
Apparel, Beverage, Chemical, Commodity, Food, Other, Medical, Textiles, Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Medical, Textiles
Packaging Type
Bags, Barrel, Bottles, Cans, Capsule, Cartons, Case, Pouch, Stand-up Pouch
Packaging Material
Glass, Metal, Paper, Plastic, Wood
Automatic Grade
Automatic
Driven Type
Pneumatic
Voltage
380V, 3P 380 V
Power
2.2KW, 8KW
Place of Origin
Shanghai, China
Brand Name
MOTECH
Model Number
BG60-4R
Dimension(L*W*H)
1100*578*1358MM
Weight
500kg, 2500KG
Certification
ISO 9001
After-sales Service Provided
Engineers available to service machinery overseas
Product Description
BG60R Automatic Filling & Sealing Machines
Automatic Filling & Sealing Machines BG60R SeriesFully automatic cup filling sealing machine can automatic complete falling cup, ultraviolet radiation sterilization, filling, sealing, cutting, printing production date, finished output processes. The machine is made of stainless steel 304 and aluminum alloy. The product contact parts made of stainless steel 316, which is produced in strict accordance with the food industry hygiene standards; Plastic tray and odd shaped tray can be customized as requirement.
Application(Automatic Filling & Sealing Machines):
Fully automatic cup filling sealing machine is widely applied to the food and beverage industry, such as milk, mineral water, jelly, oil, tea etc.
Technical Characters of Automatic Filling & Sealing Machines:
1. Control system: Omron PLC programmed control system and touch screen, Intuitive, stable, easy to operate.
2. International components: AIRTAC cylinder and solenoid value, Schneider sensor and electronic components.
3. It used the converter motor and protractor driving system ensure the precise positioning when adjust the speed.
4. Double sealing system ensure the perfect sealing quality.
5. The machine is made of stainless steel 304 and aluminum alloy, the product contact parts made of stainless steel 316, which is produced in strict accordance with the food industry hygiene standards
6. The machine used the plastic reel film to sealing the products, more economical and health.
7. The machine's filling system used the piston structure, it can accurate filling the liquid and paste material.
8. Safety guard with door switch which used for machine to pause.
9. Optional: Plastic cups detection device, Pre-cut foil detection device, double filling system, sealed cylindrical tank.
10. Special circumstances can be customized according to customer.
Technical Specification(Automatic Filling & Sealing Machines):
Model
BG60-4R
BG60-6R
BG60-8R
BG60-10R
Voltage(v)
1P 220/50 or 3P 380/50
Power(kw)
4.8
6.8
8.8
11.5
Sealing temperature
0-300
Filling range(ml)
0-250
Sealing Material
PET/PE, PP, Aluminum foil, Paper/PET/PE
Filling accuracy
± 1%
Production(cups/h)
3600-4800
5400-7200
7200-9600
9000-12000
Intake pressure(Mpa)
0.6-0.8Mpa
G. W(kg)
580
650
750
880
Dimensions
3500× 800× 1700
3500× 1000× 1700
4000× 1200× 1700
4200× 1400× 1700
