Water-cooling Color Fastness raining illumination testing machine
--Water-cooling Color Fastness To Sunlight Test Equipment
Used for testing the performance of discoloring, fading, aging, transmissibility, peeling, hardening, softening, of the products and materials in the industries of rubber, plastic, paint, petrochemicals, auto, fabric, for solar radiation simulation test( illumination, raining, temperature, humidity, )
Technical parameters
Model |
SKZ161D |
Test compartment temperature control |
30~70°C, Resolution: 0.1 °C |
Storage humidity control test |
Ming period :10-75% RH, humidity fluctuations ± 3% RH; dark cycle :10-95% RH, humidity fluctuate ± 5% RH; |
Time control experiments |
0min~999:59h, Accuracy ± 1min |
Irradiance control |
1.00-1.30W/m2/420nm Accuracy: ± 0.02 W/m2/420nm;digital set, automatic compensation. |
Control and monitoring wavelength |
Optional 340nm, 420nm ,300-400nm ,300-800nm |
Xenon arc lamp rated power |
4.5KW |
Sample holder rotation speed |
1rpm can be set |
Diameter distribution of sample clip |
φ500mm |
Maximum exposure area |
3500cm2 |
Sample holder can be mounted with the number of dimensions |
145 × 75mm model 25; 145 × 45mm model 35 |
Timing of each sample holder, respective |
≤10000h |
Photoperiod |
≤10000h |
Spray cycle |
≤10000h |
Blackboard temperature range |
(BPT) 30-90°C±2°C;(BST) 35-95°C±2°C |
Display control |
10.4-inch touch screen |
Data Output |
Digital color display (A4 print in English optional) |
Sample holder type |
Single |
External circulating water requirements |
Water pressure :140-1345kPa Flow: 1.0L/min |
Requirements within the recycled water |
High water flow: 0.5L/min |
Power supply |
AC380V±5% 50Hz 10KW |
Dimensions |
1250×830×1800mm |
Weight |
350kg |
Model |
SKZ161E |
Test chamber temperature control |
30~70°C, Distinguishability:0.1°C |
Test chamber humidity control |
light cycle : 10-75%RH, humidity fluctuation ±3%RH; shade cycle :10-95%RH, humidity fluctuation ±5%RH; |
Testing time control |
0min~999:59h, Accuracy:±1min |
Irradiance |
0.8~2.5W/m2/420nm Accuracy:±0.03W/m2/420nm, Digital setting automatic compensation |
Control and monitoring wavelength |
Optional 340nm, 420nm, 300-400nm, 300-800nm wave band |
Rated power of xenon lamp |
4.5KW |
Slewing speed of sample frame |
1-10rpm settable |
Distribution diameter of sample clamp |
φ550mm |
Maximum exposure area |
3500cm2 |
size and number of sample clamps |
145×75mm template 35 block;145×45mm template 48 pieces |
Each sample folder times respectively |
≤10000h |
Illumination cycle |
≤10000h |
Spraying cycle |
≤10000h |
Blackboard temperature range |
(BPT) 30-90°C±2°C;(BST) 35-95°C±2°C |
manipulation showing |
10.4 inch touch screen |
Data output |
Digital color display (A4 print in English optional) |
Sample holder type |
Double |
External circulating water requirements |
Water pressure :140-1345kPa Flow: 1.3L/min |
Requirements within the recycled water |
High water flow: 0.6L/min |
power source |
AC380V±5% 50Hz 10kW |
Model |
SKZ161F |
Test compartment temperature control |
20~93°C, Resolution: 0.1 °C |
Storage humidity control test |
Light cycle:10-75% RH, humidity fluctuations ± 3% RH; dark cycle :10-95% RH, humidity fluctuate ± 5% RH; |
Time control experiments |
0min~999:59h, Accuracy ± 1min |
Irradiance control |
0.8 ~ 2.5W/m2/420nm Accuracy: ± 0.03W/m2/420nm;digital set, automatic compensation |
Control and monitoring wavelength |
Optional 340nm, 420nm ,300-400nm ,300-800nm |
Xenon arc lamp rated power |
6.5KW |
Sample holder rotation speed |
1-10rpm can be set |
Diameter distribution of sample clip |
φ650mm |
Maximum exposure area |
6900cm2 |
Sample holder can be mounted with the number of dimensions |
145 × 75mm model 68; 145 × 45mm model 90 |
Blackboard temperature range |
(BPT) 30-100°C±2°C;(BST) 35-105°C±2°C |
Display control |
10.4-inch touch screen |
Data Output |
Digital color display (A4 print in English optional) |
Sample holder type |
Three |
External circulating water requirements |
Water pressure :140-1345kPa Flow: 1.5L/min |
Requirements within the recycled water |
High water flow: 0.8L/min |
