Press and Dry Fast Sheet Former
- Qingdao/Beijing
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | SKZ | |
| Model Number | SKZ125 | Power | Electronic | |
| Usage | Paper Testing Instrument |
Product Description
Specifications
ISO5269/2-Part two: the fast sheet former method. It contains one paper-making equipment and two drying equipmentPress and dry fast sheet former
Standards: ISO5269/2-Part two: the fast sheet former method. It contains one paper-making equipment and two drying equipment.
Feature:
- Mainly composed by dryers, vacuum pumps, and sheet former (press)
- Sheet former parts: power-driven drain off water, white water cycle use, power-driven feed water, aerodynamic homogenate ( also can manual homogenate), Water molding or vacuum pump suction molding
- Dry parts adopt vacuum heating and drying, vacuum pump adopts water cycle, heating element use heating plate, temperature control system, and has a short circuit, disconnection, and automatic over-temperature alarm function, with a stop anti-oil return.
- countertops and water tanks are made of stainless steel
Technical data:
1. Sample Dia.:200mm
2. Dry Dia.: Φ200
3. Height of vacuum pump: -0.06~-0.09MPa
4. Sucking rate of vacuum pump: 60CBM/H. (water cycle)
5. Drying Temp: 95°C-120°C
6. Drying time: (GSM 30-85g/m2): 3~5Minutes
7. Weight: 300KG
8. Compressor: 2P
9. Heating power: 1.5KW×2
10. Dimension: 1700mm×700mm×1200m
