High quality LED RGB touch controller factory

Specifications

High quality LED RGB touch controller factory
1.Voltage:DC12V/24V
2.three-way output
3.Output current:6A/way

High quality LED RGB touch controller factory

Production  Description

Specification	Modle	Warranty	Size(mm)      and      packing	Note
Input:12v/24v(optional) Stand-by consumption:<0.5w Working temperature:-20~60°C Connection type:three-way output,common anode Rated current:4A/way,total 12A Max power:<144w/12v,<288w/24v Output power:144w/12v,288w/24v Function:21 optional patterns,Speed and luminance adjusted	YKA6018RF12	2 years	Dimension:130*66*26mm Package size:138*83*57mm Gross weight:184g Quantity:50pcs/Ctn Ctn size:42*29*29cm
Working voltage:DC12v/24v(optional) color:black/white(option) Stand-by consumption:<0.5w Working temperature:-20~60°C Connection type:three-way output,common anode/common cathode for your option Output current:4A/way Ouput power:144w/12v,288w/24v Function:11 optional patterns,light adjusted by touch	YKA781KF12	2years	Dimension:130*66*26mm Remote size:114*56*23mm Package size:138*83*56mm N.W:178g G.W:215g Quantity:50pcs/Ctn Ctn size:42*29*29cm
"Working voltage:DC12v Working temperature:-20~60°C Connection type:one-way output Output current:6A Ouput power:(max)72w		2years	G.W:85g/pc



Summarization



This product is a novel LED controller developed by our company which can realize multistage touch dimmer. Adopting advanced touch design, through the panel controller combined with touch remote way, realize flexible control. Touch remote has good performance, beautiful, fashion, easy to use. This product suit for every occasions, such as: point light source, flexible strip, wall washer lamp, glass curtain wall light and such lighting controller.



Easy to use, have color pulley touch screen, all sorts of design and color mode at a glance, can a single point also can continuous touch to realize color mode select, users can speedily choose the needed color, and the static and dynamic mode can change freely.
