Specifications
High quality LED RGB touch controller factory1.Voltage:DC12V/24V
2.three-way output
3.Output current:6A/way
High quality LED RGB touch controller factory
Production Description
| Specification | Modle | Warranty | Size(mm) and packing | Note |
|
Input:12v/24v(optional) Stand-by consumption:<0.5w Working temperature:-20~60°C Connection type:three-way output,common anode Rated current:4A/way,total 12A Max power:<144w/12v,<288w/24v Output power:144w/12v,288w/24v Function:21 optional patterns,Speed and luminance adjusted |
YKA6018RF12 |
2 years |
Dimension:130*66*26mm Package size:138*83*57mm Gross weight:184g Quantity:50pcs/Ctn Ctn size:42*29*29cm |
|
|
Working voltage:DC12v/24v(optional) color:black/white(option) Stand-by consumption:<0.5w Working temperature:-20~60°C Connection type:three-way output,common anode/common cathode for your option Output current:4A/way Ouput power:144w/12v,288w/24v Function:11 optional patterns,light adjusted by touch |
YKA781KF12 | 2years |
Dimension:130*66*26mm Remote size:114*56*23mm Package size:138*83*56mm N.W:178g G.W:215g Quantity:50pcs/Ctn Ctn size:42*29*29cm |
|
|
"Working voltage:DC12v Working temperature:-20~60°C Connection type:one-way output Output current:6A Ouput power:(max)72w |
2years | G.W:85g/pc |
Summarization
This product is a novel LED controller developed by our company which can realize multistage touch dimmer. Adopting advanced touch design, through the panel controller combined with touch remote way, realize flexible control. Touch remote has good performance, beautiful, fashion, easy to use. This product suit for every occasions, such as: point light source, flexible strip, wall washer lamp, glass curtain wall light and such lighting controller.
Easy to use, have color pulley touch screen, all sorts of design and color mode at a glance, can a single point also can continuous touch to realize color mode select, users can speedily choose the needed color, and the static and dynamic mode can change freely.
Our service
For all your inquires about us or our products, we will reply you in detail within 24 hours
We own well-tranied and passional sales & after- sale services who can speak fluent Engligh language
We offer OEM services. Can print your own logo on product , can customize the retail box packing and other things.
We have very experienced R&D engineers and we have strong ability to do ODM projects.
