Home > Products > Cooling fan > 120mm Industrial Exhaust Fan / 120x120x25mm Equipment Cooler Fans

120mm Industrial Exhaust Fan / 120x120x25mm Equipment Cooler Fans

FOB Price

US$ 1 - 15 / Piece

500 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Application	Other, computer case. power supply	Type	Fan
Heatsink Material	Other, plastic	Brand Name	Yimeng
Model Number	YM1212PTS(B)1	Place of Origin	Guangdong, China

cooling fan YM1212PTS(B)1 for computer case cooling system

Size(mm)	Model	Rated voltage (v)	Operating Voltage Range(v)	Current amp (Amp)	Rated Input Power Watt	Speed (rpm)	Max air Flow(CFM)	Max Static Pressure (Inch-H2o)	Noise Leve (dB-A)	Weight (g)
120 * 120 *25	YM1212PTS(B)1	12	7.0 to 13.8	0.22	2.64	2200	74.1	0.2	40	140

Detail introduction

1. Expexted life

1). Ball Bearing 50,000 hours(40⁰C)

2). Sleeve Bearing 30,000 hours(40⁰C)

2. Allowable Ambient Temperature Range:

1). -10⁰C~+70⁰C (Operating)

2). -40⁰C~+70⁰C (Storage)

3). non-condensing environment

General Specification

Frame	Plastic(UL94V-0)
Impeller	Plastic(UL94V-0)
Bearing Type	Sleeve Bearing & Bual Ball Bearing
Leadwire	UL1007AWG24 or Equivalent (+): Red (-0 Black
Motor	Impedance Protected and Reverse Polarity Protected

Hope to cooperate with you, welcome to comtact with us.
