Product Details
| Electric Current Type | DC | Mounting | Duct Fan | |
| Blade Material | Plastic | Place of Origin | Guangdong, China | |
| Brand Name | MX/ODM/OEM | Model Number | MX1208ABH1 | |
| Voltage | 12V | Power | 2.76W | |
| Air Volume | 35.00CFM | Speed | 3000RPM | |
| Certification | Other, UL, CE, ISO9000, UL ,CE, RoHS, TUV |
Product Description
12V DC air conditioner fan 80mm
General Specifications:
Frame: plastic(UL94v-0)
Impeller: plastic(UL94v-0)
Bearing type: Sleeve Bearing and Dual Ball Bearing
Leadwire: UL007AWG#24 or Equivalent (+):Red(-):Black
Motor: Impedance Protected and Reverse Polarity Protected
Expected Life:
1.Ball Bearing 50,000 hours(40centigrade)
2.Sleeve Bearing 30,000 hours(40centigrade)
Allowable Ambient Temperature Range
1.-10c~+70c (Operating)
2.-40c~+70c (Storage)
3.(non-condensing environment)
Application:
Q1. Are you factory?
A1.Yes.welcome to visit our factory.
Q2. All products have a warranty?
A2.Yes. All kinds of products at least 1 year warranty.
Q3. Can we design packaging?
A3. Yes.Default is regular packing,we can make customer's own packing.
Q4. Can we add our logo on products?
A4. Yes.
Q5. How to control the quanlity of products in your company.
A5: 100% total testing before each of fan leaves our factory.
Q6. can we customize product?
A6. Yes, OEM&ODM.
