Two Axle Low Bed Semi Trailer

Two Axle Low Bed Semi Trailer thumbnail-1
Two Axle Low Bed Semi Trailer photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Type:
Semi-Trailer
Material:
Steel
Place of Origin:
Anhui, China
Contact Supplier Request Quote Chat Now
Wuhu CIMC RuiJiang Automobile Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Semi-Trailer
Material Steel
Place of Origin Anhui, China
Brand Name CIMC
Model Number ZJV9230TD

Name of product: Two-axle low bed semi trailer
Model: ZJV9230TD
Dimensions
Overall length 12000mm
Overall width 3000mm
Effective platform: 8000mm
Effective platform from ground height: 1200mm
(The above dimension will be adjusted according to the tractor specification )
Capacity
Loading capacity: 30ton
Running gear

FUWA high quality Trailer Axle 13Ton, Two Units;
Tires: 11R22.5 8PCS,
Wheel Rim: 8.5-22.5 8PCS;
Kingpin 3.5" bolted type.
Longitudinal beams: Top flange 16mm, bottom: 18mm, middle thickness: 10mm. Height: 500mm
Platform: 4mm thickness checked steel floor
Ramp: 2 units 720mm width spring ramps
Suspension: Spring suspension
Brake system: Dual air brake system, relay valve made in China, no ABS brake system
Landing leg: 28T.

Accessories
Spare tire carrier: 2 Nos.
Tool box: 1 PCS.
Other terms are in accordance with the Standards of CIMC Ruijiang.
Painting
Before the painting, surfaces and accessories are made smooth and then cleaned with a mixture of chemicals; Steel blasting completely;
Painting color is according to customer's wish.
Package
Shipped by bulk vessel with whole unit. Package three unit together
