| CIMC 50m3 aluminium Alloy fuel tank semi-trailer | ||
| PARAMETER | Dimension(mm) | L*w*h: 12980*2500*3990(mm) |
| Axle space(mm) | 7000mm+1310mm+1310mm | |
| Tare weight(kg) | 6980kg | |
| Loading capacity | 50000L | |
| OEM | Landing gear | Two speed manual operation type with sand shoe |
| Kingpin | 2" bolted type | |
| Brake system | Dual line pneumatic brake system. | |
| Brake chamber | Type 30/30 spring brake system on all axles | |
| Suspension | common suspension | |
| Axle | RJST/BPW/FUWA axle, 12 ton capacity/set,3pcs | |
| Tire | 12R22.5 12PR , 12 pcs | |
| Rim | 9.0*22.5 12 pcs | |
| Tool box | 0.8 meters toolbox,one pcs aluminum alloy | |
| Spare tire carrier | two pcs,aluminum alloy | |
| TANK SPECS | Compartment | One or according to your requirment |
| Tank material | aluminum alloy, thickness 6mm | |
| Bulkhead | Thickness is 7mm | |
| Baffle | Thickness is 7mm | |
| Shape of tank | Ellipse (double “d”) | |
| OTHERS | Fire extinguisher | 2 pcs |
| Manhole | two manhole | |
| Discharge hose | 6m | |
| Painting | Sand blasting before painting;one coats of primer, anti corrosion,two coat of finish painting;colour advised by client | |
1. Why you choose us?
CIMC RUIJIANG is a special vehicle manufacturer that belongs to CIMC group .We have more than 10 years produce experience.And our company produces at least 300 varieties of special vehicles of more than 10 series.
2. How to trust us?
Following the business philosophy of our company which is“your partner for modern transportation”,the sales network of CIMC RUIJIANG has been covering China mainland and global markets including Asia, Africa, South America, East Europe, etc. and welcome visits our company at any time.
3. How about the delivery time?
Most of our trucks are all have in stock ,We can delivery to you within 7 days, if specially ordered , we always need around 30 days for production.
4.How do you ensure the quality of product?
Our Factory is standard production workship,got ISO CCC BV ASME Certification,our workers are well trained. Our very product under goes a scrutinizing inspection process.
