Specifications
material: PLA or ABSdiameter: 1.75mm or 3.0mm
color: more than 20 colors
packing: 1kg/spool/polybag/box, 12box/carton
ABS is commonly used in 3D printing, has the following characteristics:
(1) high strength, good toughness;
(2)density is small, when printing larger volume model lighter, save money;
(3) cost-effective, can be processed in wide range temperature;
(4) softer than PLA;
(5) diameter of 3.0/1.75mm, variations + /-0.1mm,roundness +/-0.05mm;
(6) 1 kg /plastic spool packaging, can be automatic feed;
(7) to be applied to a variety of 3D printer, Makerbot, Mendel, Prusa, Huxley, BFB series, etc..
Our ABS filament advantages compare to other ABS filament:
We select of premier grade ABS material, low water absorption, high tough. Factory direct sales, inexpensive, buy more, bigger discount! !
|
3DD ABS |
ordinary ABS |
Natural color |
Milk white |
light yellow |
Processing temperature |
230 deg |
230-250 deg |
Odor |
low smoke ,tasteless |
white smoke, concentrated flavor ,make headache |
Roundness |
+/-0.05mm |
+/-0.03~0.08mm |
water absorption |
Very low, no bubbles occur when printing even expose to air for over half a year |
High, much bubbles printing at high temperature after the filament opened from seal packaging and exposed to air for a period( like one month or shorter time) |
Surface gloss |
Normal |
Good |
Production Control
1.Produce process
I . Before produce extruding filament ,we will dry ABS and PLA for a enough time (3-5 hours).
II. Mix with colors masterbatch or colors powder, all which .certified with ROHS.
III.Adjust temperature and dragging rate , make filament diameter range at 1.6-1.8mm/2.8-3.0mm, roundness +/-0.05mm, each spool net weight 1kg+/-0.05kg
IV we put all filament spool in shelf, different kind in different shelf, all categories arrange orderly.
2.Productiong quality control
I. we have diameter laser detect kits to control extruding rate on line, when diameter smaller or higher than accept range, the laser detect kits will adjust the extruding rate higher or smaller to make diameter range at acceptable.
II.keep each record filament samples sent to customers, build a tracking able document.
III.when the filament put on shelf longer than half a year, we will dry the filament again.
3.About waste & recycle
Much time you will find some black filament is too brittle, that added and mixed with some recycle and scrap after produced.
We haven’t produced with scrap outlet, rework&recycle material, or dispose, but for quality assurance purpose.
4.packaging
We put each filament /spool on seal PE bag with desiccant , then smaller carton, then out big box
We also have vacuum heated bag to replace of PE bag, make better avoid moisture.
5.research and developing
we have engineers that specialty in color formulation ,plastic modification, packaging, quality control ,producing control, we can do according to your requirements .
we have colors:
Natural, white, black,red, sky blue, dark blue ,florescent green,dark green, florescent yellow, dark yellow ,orange, purple, pink, grey, brown,glow in dark etc
ABS grade imported from Taiwan Chimei properties:
Property |
|
Test Method |
Test Condition |
3DD ABS |
|
kg/cm2 |
ASTM |
23°C |
220 (22) |
|
% |
ASTM |
23°C |
40 |
Flexural Strength |
kg/cm2 |
ASTM |
23°C |
440 (43) |
|
kg/cm2*104 |
ASTM |
23°C |
2.3 (2260) |
Izod |
kg-cm/cm |
ASTM |
23°C |
11.0 (108) |
|
°C |
ASTM |
Annealed |
95 |
|
°C |
ASTM |
Annealed |
88 |
Melt |
g/10 min |
ASTM |
200°C×5Kg |
5.5 |
Residual Monomer |
ppm max. |
|
|
700 |
Molding |
% |
FCFC |
23°C |
0.4~0.6 |
Specific Gravity |
|
ASTM |
23°C/23°C |
1.04 |
Flammability |
|
UL-94 |
FILE NO. |
1/16" HB NC |
Payment accept:
Paypal
Bank account wire
Western Union wire
Shipping:
1.go by express,
if you live where far from China(like Russia, Middle East, East Euro, South America ,Africa), we will choose go by china post, maximum 2kg, , it is cheaper go by air when quantity bigger than 50kg .
if East/South Asian, West Euro, North America, Australia are good price go by express and not quantity limited.
2.go by sea,
when quantity more than 300kg, we can go by sea, it is very cheap, about $350 -500.and some fee you should pay to local port and warehouse, you can contact the shipping company to take the goods from port to your address.
Order quantity from factory:
We have 3 tons in stock each month,about 50-100kg of each kind .
when you can order one material(PLA or ABS), one color (natural,white,black,red,green,yellow,orange,blue,purple, grey),one diameter(1.75/3.0mm), minimum quantity 100kg, you can get the best and smallest factory price, you can start from natural,white,black, since these three colors are sale well;
