Help Center16Y-63T Single-cylinder Hydraulic Punching Machine
Related Products
-
20Y-90T Single Cylinder Hydraulic Punching MachineUS$ 1,000 - 50,000MOQ: 1 Set -
25Y-115T Single-cylinder Hydraulic Punching MachineUS$ 1,000 - 50,000MOQ: 1 Set
-
Hydraulic Punching Machine, Pipe Punching MachineUS$ 1,000 - 170,000MOQ: 1 Set
-
Hydraulic Punching Machine, Muti-function Punching MachineUS$ 5,000 - 50,000MOQ: 1 Set
-
Steel Metal Hole Punch Machine , Hydraulic Punching MachineUS$ 5,000 - 50,000MOQ: 1 Set
Specifications
1.Simple structure2.Easy operate
3.High precision...
4.Our lastest new model
5.own patent
Features
Using hydraulic transmission , is China’s currently latest Multi function United punching machine products , can plate Flat steel ,
square steel , round steel , angle steel , channel steel ,I beam to punch
| Technical Parameters | |
| Model | 16Y-63T |
| Punching Pressure(T) | 63 |
| Plate strength(N/mm2) | ≤450 |
| Slider trip(mm) | 80 |
| Trips frequency(times/min) | 14-25 |
| Punching Thickness(mm) | 16 |
| Max.punching diameter(mm) | 25 |
| Throat depth(mm) | 300 |
| Main Motor Power(KW) | 4 |
| Overall diamensions(L×W×H)(mm) | 1400×700×1700 |
Company Introduction
Anhui Zhongyi Machine Tool Co., Ltd. specializes in the production of "Yuanyi" series
bending machines, metal plate shearing machines, Press brake , punching & shearing
machines and forging and pressing dies. Our company was established in 2003 and
there are 78 staff members. Our products have won good appreciation from customers
since entering the market. We supply good pre-sales service, during-sales service and after-sales service. These services meet users' demands.
Skype:amywang620720
Cell phone:0086-15375552121
