Help CenterVariable PCD Hex Ball Seat Wheel Screw Bolt
Related Products
Specifications
1) ISO 9001 & TS16949, SGS,BV,TUV2) lower price
3) higher quality
4) better Service.
5) over 72hrs neutral salty spary test
Variable PCD alloy steel bolt
Item No.: 12V94701
* 2/3" hex 54mm total length, 28mm thread length ball seat SR 12
Electroplating
* We are the first and unique one in China, own autometic electroplating production line, Our products passed above 72 hours NSS neutral salty spray test. the thinckness of nickle more than and equal to 30 ,thinckness of chrome equal to 3
Thread Size Available
* M8*1.25, M10*1.25, M10*1.50, M12*1.25, M12*1.50, M14*1.25, M14*1.50, M14*2.0, 3/8"-24,7/16"-20, 1/2"-20, 9/16"-18, etc.
Finish Available
* Chrome, Zinc, Dacromet, Blacking, Color Electrophoretic, etc
Availabe in different colors. color code like below list
Material
* Carbon Steel, Alloy Steel, Heat-treatment, we purchase 80% steel from Shanghai baogang ------ one of China's most famous company
Mechanical performance grade
* 8 or 10 grade, acquiesce in 6 grade
Packages Available
* double blister (clamshell) , cardboard box, head card, plastic box, foam box or brown paper.
*We here only list the regular specification, please inform us if you have any requirement for different design or size.
Certificate
Utility Model Patent
Manufacturing Systems
Test and Measurement Center
