Specifications
MCU voice , sound recording chip , sound chip*voice+8bit MCU,1 chip solution
*8 programable I/O
*support writer/copier
Specifications
MCU voice , sound recording chip , sound chip
*voice+8bit MCU,1 chip solution
*8 programable I/O
*support writer/copier
8 bit MCU Voice Chip - 42 sec sound recording chip , voice recording ic , sound chip
Feature :
.Standard CMOS process.
.Embedded EPROM.
.Embedded 8-bit MCU.
.42sec voice duration at 6 KHz sampling with 4-bit ADPCM compression.
·Caculating above duration is base on 6Khz, 4bit ADPCM. User can define higher sample rate or
choose 5 bit u-law or 8 bit PCM for better quality, but duration will be shorter
.Combination of voice building blocks to extend playback duration.
.Table entries are available for voice block combinations.
.User selectable PCM or ADPCM data compress.
.Voice Group Trigger Options: Edge / Level; Hold / Un-hold; Retrigger / Non-retrigger.
.Programmable I/Os, Timer Interrupt and Watch Dog Timer.
.Built-in oscillator with fixed Rosc, software control sampling frequency
.2.2V – 3.6V single power supply and < 5uA low stand-by current.
.PWM Vout1 and Vout2 drive speaker directly.
.D/A COUT with ramp-up ramp-down option to drive speaker through an external BJT.
